The Gartec NP1110 part number, 1:1 ratio wall pump is part of the standard series, specifically designed for reliable and efficient fluid handling tasks, especially in workshops and industrial environments. This pneumatically operated unit is the ideal choice for dispensing new oils, ensuring precise and continuous flow.
This wall pump is an integral part of the Gartec FLUID CONTROL TECHNOLOGY offering, which includes a wide range of pneumatic pumps, electric pumps, hose reels, and other fluid handling systems.
The NP1110 model is excellently suited for pumping more viscous materials, such as new oils, thanks to its 1:1 compression ratio, which ensures that the output pressure closely matches the inlet air pressure while guaranteeing high throughput.
Single Acting Design: The pump has a simple operation, which increases reliability and reduces the risk of potential malfunctions.
High Flow Rate: With a maximum flow rate of 22 liters/minute, it enables fast and efficient fluid transfer.
Wall-Mountable Design: Wall mounting provides a space-saving solution, making the pump ideal even in tight work areas.
Robust Construction: The weight of 5.5 kg and quality materials guarantee a long service life even under intensive use.
This pump is specifically optimized for the transfer of the following fluids:
Although the pump is primarily recommended for new oil, the wide product range from Gartec also offers dedicated solutions for other fluids (e.g., used oil, AdBlue, antifreeze, water).
The detailed technical specifications for the NP1110 wall pump are as follows:
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | NP1110 | – | Standard Series |
| Flow rate | 22 | l/perc | Maximum performance |
| Operating pressure | 4 – 8 | bar | Air Inlet Pressure |
| Operating pressure | 58 – 116 | kPa | Air Inlet Pressure |
| Compression Ratio | 1:1 | – | Single Acting |
| Air consumption | 340 | l/perc | Operating Air Requirement |
| Noise Level | 79 | dB | Noise level during operation |
| Suction Hose Size (Diameter x Length) | 42 x 290 | mm | Dimensions of the suction hose |
| Weight | 5.5 | kg | Net Weight |
| Packaging size | 150 x 150 x 620 | mm | Box Dimensions |
The pump connections ensure easy integration into standard industrial systems:
Air Inlet Connection: 1/4″ external thread (thumbs 1/4″ F)
Fluid Inlet Connection: 1″ internal thread (thumbs 1F)
Fluid Outlet Connection: 1/2″ internal thread (1/2 „M)
To optimize the performance of the Gartec NP1110 pump and facilitate installation, the use of the following accessories is recommended:
Pressure Regulator: Essential for setting the precise operating pressure and protecting the pump.
Suction Kit for 200 Liter Drum (Suction Kit for wall-mounted pumps – Model NV9027): Enables direct connection of the pump to a standard 200-liter oil drum.
Ring nut for securing pumps to drums (Ring nut for securing pumps to drums – Model NV9006): For mounting to a drum with a Ø42 mm diameter, ensuring stable positioning.
Wall bracket with ring nut (Wall bracket with ring nut diam. 42 mm): If you wish to install the pump on a fixed wall instead of making it portable, this mounting element ensures adequate stability.
This 1:1 ratio wall pump is the ideal solution for environments requiring reliable, continuous dispensing, such as:
Vehicle Service Stations and Auto Repair Shops: Precise dosing of new motor oils and gear oils.
Industrial Maintenance Parts: Transfer of lubricants and hydraulic fluids from storage containers to dispensing points.
Production lines: As a component of simple, pneumatically operated dosing systems.
The Gartec NP1110 standard wall pump offers the perfect combination of durability, efficiency, and ease of installation for managing new oils.
