This detailed product description refers to the Wieländer+Schill adapter ring with part number HV155, which was specifically developed for the WS Roller-Spinner system. This component is essential for servicing and moving vehicle wheels, ensuring precise operation and stability.
The HV155 adapter ring is a special accessory that must be mounted onto the 5/6 steel flange. Its main function is to enable the spin mode activation on the WS Roller-Spinner unit, while guaranteeing optimal wheel stability during operations.
The product fully includes the screws necessary for fastening, so installation can be done quickly and easily with the appropriate tools. Made of steel, its robust design guarantees a long service life and high load capacity in the workshop environment.
This adapter ring is a crucial element for body repair shops where the positioning and movement of vehicle wheels require high precision, especially during painting or other bodywork tasks.
The table below summarizes the most important technical parameters of the Adapter Ring with 5/6 Screws | WS Roller-Spinner (HV155): | Feature | Value | Note | | :------ | :------ | :------ | | Part number | HV155 | Unique Identifier | | Compatibility | Steel Flange 5/6 | For the Roller-Spinner System | | Function | Enabling Spin Mode and Wheel Stabilization | | | Fixation | Fastening Screws Included | Included in the package | | Diameter (Ø) | 185 mm | Outer diameter of the ring | | Bolt Circle | 5/6 | Layout of the fastening holes | | Dimensions (Length x Width x Height) | 215 x 215 x 20.5 mm | Total physical dimensions | | Material | Steel | High-strength construction | | Weight | 5.0 kg | Product weight | | Package Contents | 1 piece (1 stück, 1 piece) | One unit |
By using the HV155 adapter ring, users can benefit from the following advantages:
Precise Wheel Movement: The adapter ensures that the wheel remains perfectly stable even in spin mode, minimizing unwanted displacement.
Egyszerű Telepítés: Thanks to the included fastening elements, the ring can be quickly and securely fastened to the 5/6 steel flange.
Durability: The use of steel material guarantees the tool's resistance against the mechanical stress typical in workshops.
Compatibility: An accessory specifically optimized for the WS Roller-Spinner system, ensuring the performance guaranteed by the manufacturer.
This part is the ideal choice for any professional body repair shop that uses the Wieländer+Schill WS Roller-Spinner system for vehicle servicing, especially in cases where fine-tuning and stabilizing the wheel position is essential.
The Adapter Ring can be categorized under the following product categories in the Wieländer+Schill offering:
Main Category: PRODUCTS
Subcategory: Service & Workshop
Product Group: Car Dollies – Although this is an adapter, its function is closely related to the movement and positioning of vehicles.
The product is part of the broader Wieländer+Schill portfolio, which includes XSeries riveting technology, welding techniques, panel separation tools, and other body repair solutions.
