Intercomp low and medium capacity jack weighing (Jack Weigh) systems offer the most reliable solution for the precise determination of aircraft center of gravity and weight distribution. These systems are ideal for applications where precise knowledge of total weight and axle loads is essential for safe operation, maintenance, and weight & balance calculations.
These systems are excellently suited for weighing smaller and medium-sized aircraft, helicopters, as well as special-purpose aircraft, where traditional platform scales cannot be used or are impractical.
Intercomp jacking scale systems offer a combination of accuracy, portability, and user-friendly design:
High Accuracy: They provide extremely accurate measurements, specifically compliant with aerospace requirements, minimizing weight and balance calculation errors.
Modular Design: The systems are flexibly configurable for different aircraft types and weight ranges.
Robust Construction: Designed to withstand the rigors of the airport environment, ensuring long service life and reliability.
Wireless Communication: Optional RFX® wireless technology enables convenient reading of measurement data near the aircraft, increasing safety and operational efficiency.
Egyszerű Telepítés: The systems can be positioned quickly and easily under the aircraft jacking points, minimizing downtime.
The low and medium capacity category covers the most common maintenance and weight & balance requirements.
The AC100™ kit is a reliable, basic solution for weighing smaller and medium-sized aircraft.
Area of application: General maintenance, weight & balance.
Configuration: Robust, easy-to-handle components.
This advanced kit integrates wireless technology for maximum flexibility and user convenience.
Wireless Indicator: Can be used with the RFX® wireless handheld indicator or a CPU (e.g., RFX® Wireless AC100™ Aircraft Scale CPU).
Advantage: The operator can monitor the measurement from a safe distance, without having to be directly near the load cell.
The performance of Intercomp systems is completed by their associated displays, software, and calibration devices.
The accuracy of measurement and data handling is ensured by the following devices:
| Device Name | Típus | Function |
|---|---|---|
| TAC30™ CPU | Touchscreen Indicator | Intuitive user interface, advanced data processing. |
| RFX® Wireless Handheld Indicator | Wireless Handheld Display | Real-time, wireless data transmission. |
| RFX® Wireless AC100™ Aircraft Scale CPU | Wireless Central Unit | Wireless data acquisition hub optimized for AC100™ kits. |
| ACWeigh™ Software | Software | Data management, report generation, and archiving. |
| iACWeigh™ | Mobile Application | Data acquisition and management via mobile devices. |
To maintain the accuracy of the scales, Intercomp offers comprehensive calibration solutions:
CSM™ Manual Test Stand: Reliable, manually operated device for checking and calibrating load cells.
CSA™ Automated Test Stand: Offers higher throughput and automated test protocols for fast and precise checking.
These systems are crucial in the following aerospace segments:
Low Profile, Low Capacity Aircraft: Smaller single- and multi-engine aircraft, light sport aircraft.
Low Profile, Medium Capacity Aircraft: Maintenance phases for mid-sized business jet engines and regional airliners.
eVTOL Development: Extremely precise determination of the center of gravity and load distribution for prototypes of electric vertical take-off and landing (eVTOL) vehicles during the development phase.
General Weight & Balance Checks: For periodic checks and substantiating flight plans.
Intercomp not only supplies measuring equipment but also ensures user expertise:
Intercomp's low and medium capacity lift scale systems are the foundation of aerospace engineering work. Robust hardware, advanced wireless technology, and extensive software support guarantee that weight and load measurements always meet the highest accuracy requirements, thus supporting the safe operation of aircraft throughout their entire service life.
