The Alfen EVE Single Pro-Line is a compact yet extremely robust charging solution, specifically designed for private and semi-public areas. This high-quality, European A-grade product offers a reliable and flexible charging experience for Electric Vehicles (EVs) and Plug-in Hybrids (PHEVs).
The charging station is enclosed in a polycarbonate housing, resulting in a lightweight yet extremely durable structure. It can be installed wall-mounted or as a freestanding unit with an optional pole, ensuring maximum flexibility regarding the installation environment.
The EVE Single Pro-Line series features several advanced functions that optimize the charging process and user experience:
Compact and Modern Design: Extremely small, modern housing design that aesthetically fits into any environment.
Flexible Power Output: The charging capacity is adjustable over a wide range, from 3.7 kW up to 22 kW (on 1 or 3 phases).
Display and User Interface: Features a 3.5-inch color display, configurable in different languages, improving user interaction.
Integrated RFID Reader: The built-in RFID card reader enables secure identification and initiation of the charging process (Sign in with charge card).
Plug & Charge Capability: Supports the Plug & Charge function for even simpler and faster startup.
Intelligent Load Management: Possibility of dynamic load balancing through cooperation with a smart meter, which prevents network overload.
MID Certified Meter: The built-in energy meter with MID certification allows for accurate billing of transactional costs, ideal for semi-public use.
Service Provider Freedom: SIM-lock free design, ensuring free choice regarding the Charging Service Provider (CSP).
Compatibility: Compatible with the Cohere Maxem Energy Manager system for optimizing energy consumption.
European Quality: Reliable and excellent quality product that complies with strict European standards.
The Alfen EVE Single Pro-Line offers several configuration options to meet individual requirements:
The device's load capacity can be adjusted to the installed network conditions:
| Number of Phases | Stromstärke | Maximum Power |
|---|---|---|
| 1 phase | 16A | 3.7 kW |
| 1 phase | 32A | 7.4 kW |
| 3 phase | 16A | 11 kW |
| 3 phase | 32A | 22 kW |
The charging station is available in two main versions:
Socket version: Allows the user to connect their own charging cable.
Version supplied with a fixed cable: It has an integrated cable, optionally available in 5 or 8 meter lengths.
Cable Type: Type 1 or Type 2 cable.
Connector Holder: The Type 2 connector holder is integrated into the housing.
Load balancing function is selectable:
Without Load Balancing
With Load Balancing (Supports Dynamic Load Management)
User identification can also be configured:
With RFID card registration
Without RFID card registration
| Parameter | Details |
|---|---|
| Brand | Alfen |
| Product Family | EVE Single Pro-Line |
| Design | Compact, wall-mounted or freestanding (with pedestal) |
| Housing Material | Polycarbonate |
| Weight | 4.5 kg |
| Dimensions (H x W x D) | 37 × 24 × 13 cm |
| Maximum Power | 22 kW (3 phase, 32A) |
| Minimum Power | 3.7 kW (1 phase, 16A) |
| Display | 3.5" color display with multilingual support |
| Communication | SIM-lock free, supports Plug & Charge |
| Measurement | Energy meter with MID certification |
| Cable length options | 5 meters or 8 meters (in case of fixed cable version) |
| Color | white |
| Specification | European A-Quality |
This charging station is the ideal choice for those seeking a reliable, intelligent, and future-proof charging infrastructure, whether for residential, office, or commercial environments. Detailed technical specifications and flexible configuration options guarantee that the system can be perfectly integrated into the existing electrical grid and user requirements.
