This detailed product description presents the high-quality, straight design, 550 mm long electrode set by Wieländer+Schill, specifically developed for resistance spot welding applications. This set is essential for professional body repair work, ensuring reliable and efficient welding performance.
The Electrode Set No. 52 a specially designed, water-cooled electrode set with a straight geometry and a length of 550 mm, ideal for working in hard-to-reach areas. The set is exclusively for the InvertaSpot GT type welding machine X-Trafogun unit, guaranteeing optimal performance and system integration.
Made from high-quality CuCrZr (Copper-Chromium-Zirconium) material usage ensures the long service life of the electrodes, excellent electrical conductivity, and resistance to high-temperature loads, which is essential for creating durable and high-quality weld seams.
Water Cooling: The built-in water cooling system efficiently reduces the temperature of the electrode tip during continuous, high-intensity welding cycles. This significantly extends the electrode life, reduces maintenance requirements, and ensures consistent weld quality throughout the shift.
Straight Geometry: The straight design allows access to body panels where angled or bent electrodes cannot be used, maximizing workspace flexibility.
Greater Length (550 mm): The 550 mm length is critical for reaching deeper or more distant welding points, especially on the complex structures of modern vehicles.
Excellent Material Quality: The CuCrZr alloy provides excellent mechanical strength and outstanding conductivity, which is essential for optimal current transfer and applying the correct welding force.
Compatibility: Optimized specifically for the InvertaSpot GT X-Trafogun, guaranteeing a perfect fit and maximum performance within the Wieländer+Schill welding system.
The table below summarizes the most important technical parameters of Electrode Set No. 52:
| Property | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | 495775 | – | Product Identifier |
| Content | 1 set | – | Quantity in Package |
| Length | 550 | mm | Total length of the electrode |
| Material | CuCrZr | – | Copper-Chromium-Zirconium Alloy |
| Welding Force | 0,400 | kN | Maximum Recommended Welding Force |
| Operating Pressure (Cooling) | 6 | bar | Optimal pressure of the cooling system |
| Weight | 4,249 | kg | Net weight of the set |
| Construction | straight | – | Geometric Shape |
| Cooling | Water | – | Built-in Water Cooling |
| Compatibility | InvertaSpot GT X-Trafogun | – | Usable exclusively with this type |
This electrode set is the ideal choice for any professional body shop that requires high-precision, durable resistance spot welding, especially for:
Body Repair: Welding of steel and high-strength steel (HSS/UHSS) components on modern vehicles.
Hard-to-Reach Spots: The long, straight design allows for welding internal reinforcements and double-walled structures.
High-Volume Shops: The water cooling ensures continuous, uninterrupted work, minimizing downtime.
Wieländer+Schill products comply with the highest industrial standards. Manufacturing processes are carried out under strict quality control, confirmed by ISO 9001 certification. To achieve optimal product performance, use is recommended exclusively with the specified welding equipment (InvertaSpot GT X-Trafogun). Maintaining an operating pressure of 6 bar in the cooling system is essential to maximize the lifespan of the tips.
This electrode set is part of the professional welding technology portfolio of Wieländer+Schill, which focuses on reliability and long-term performance.
