Part number: 495730
This high-quality, water-cooled electrode set is part of the Wieländer+Schill professional welding technology range, specifically designed for resistance spot welding applications. The set includes straight and bent electrodes, ensuring optimal access and efficiency during body repair work.
This electrode set is exclusively for use with the InvertaSpot GT type welding machine X-Trafogun can be used as a unit. The component intended for professional use guarantees reliable and durable welding results, meeting the highest industrial requirements.
The 280 mm long electrodes are ideal for work areas where standard dimensions are insufficient, or where the bent shape is advantageous for reaching hard-to-access points. Water cooling ensures increased electrode life and continuous, high-quality welding performance, minimizing the risk of overheating even during intensive use.
Two Geometries: The set includes straight and bent electrodes, providing flexibility for various welding positions and body panels.
Excellent Cooling: The water-cooled design is critically important for high-performance spot welding as it maintains a stable temperature, thereby reducing electrode wear and electrode tip deformation.
High Clamping Force: The maximum force of 1300 kN (kilonewton) ensures adequate compression between the materials to be welded, which is essential for creating strong and high-quality weld seams.
Durable Material Use: Electrodes made from CuCrZr (Copper-Chromium-Zirconium) alloy offer excellent electrical conductivity and mechanical strength, even at high temperatures.
The table below details the specifications of the electrode set, which are essential for verifying compatibility and performance:
| Property | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | 495730 | – | Unique Identifier |
| Construction | Straight / Bent | – | Two shapes in the set |
| Length | 280 | mm | Total length of the electrode |
| Material | CuCrZr | – | Copper-Chromium-Zirconium Alloy |
| Maximum Force | 1,300 | kN | Force exerted by the welding gun |
| Operating Pressure | 7 | bar | Optimal pressure of the cooling system |
| Weight | 2,907 | kg | Net weight of the complete set |
| Cooling | water-cooled | – | Active Cooling System |
| Compatibility | InvertaSpot GT (X-Trafogun) | – | Exclusive Compatibility |
| Package contents | 1 set | – | Content: 1 set |
This electrode set is primarily ideal for workshops specializing in automotive body repair using resistance spot welding. The 280 mm length and the bent shape allow access to weld points on the internal structural elements of vehicles where space is limited. Water cooling ensures that operations can be performed quickly and without interruption, which increases workshop productivity.
The use of CuCrZr material guarantees that the electrodes withstand high temperatures and mechanical stress, ensuring consistent weld quality over the long term, which is essential for returning to factory specifications.
Wieländer+Schill is committed to the highest quality standards. The product complies with strict quality management systems, which are also proven by the following certificates:
ISO 9001: Quality Management System
ISO 14001: Environmental Management System
This professional electrode set combines reliability and precision, supporting efficient and durable body repair work.
