The NP3001 part number electric gear pump is a reliable and compact solution from the Gartec Fluid Control Technology range for pumping new oils in workshop environments and lubrication systems. This unit, powered by 230V mains voltage, is excellently suited for precise dosing, ensuring continuous and efficient fluid movement.
The NP3001 model is a robustly built, electrically driven gear pump specifically designed for new oils transfer. Its compact dimensions and reliable performance make it ideal for both smaller workshops and larger maintenance facilities where precise and controlled oil dispensing is required.
The pump provides a maximum flow rate of 9 liters/minute, which is sufficient for most routine lubrication tasks. The maximum operating pressure of 11 bar (PSI) ensures that the fluid can be efficiently delivered to the desired point, even against back pressure. The 550 W motor provides enough power for continuous operation, while the 1450 revolutions/minute speed creates an optimal balance between performance and service life.
The pump's design allows for simple installation and maintenance. Both the inlet and outlet connections feature a 1-inch thread, ensuring a standardized fit with most industrial hoses and pipes.
Compact Design: Easily integrable into existing systems or mobile units.
Reliable Performance: Gear technology ensures a constant flow rate.
Area of Application: Ideal for pumping new oils, including lubricants and other designated hydrocarbon-based fluids.
Easy Operation: Standard 230V mains connection.
Alacsony Zajszint: 77 dB(A) noise level during operation, contributing to a more pleasant working environment.
The technical parameters of the NP3001 model are summarized in the table below, providing a detailed overview of the pump's capabilities:
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | NP3001 | – | Gartec Identifier |
| Flow Rate (Scope) | 9 | l/perc | Maximum Capacity |
| Operating Pressure (Working pressure) | 11 | bar / PSI | Maximum pressure rating |
| Power (Watts) | 550 | Watt | Power Consumption |
| Voltage (Volt) | 230 | Volt | Mains voltage |
| Speed (Turns/Minute) | 1450 | rpm | Motor Speed |
| Noise Level (Noisiness) | 77 | dB | Operating noise level |
| Input Connection (Input connection) | 1 | inch | Standard threaded connection |
| Outlet Connection (Outlet connection) | 1 | inch | Standard threaded connection |
| Weight | 9 | kg | Net Weight |
| Packaging Size (Packaging) | 350x280x280 | mm | Box Dimensions |
This pump is specifically optimized for the transfer of the following fluids:
Although Gartec offers a wide selection for other fluids (e.g., used oil, AdBlue, antifreeze), the NP3001 model is primarily calibrated for handling new, clean oils.
The NP3001 electric gear pump performs excellently in the following areas:
Vehicle Service Stations and Workshops: Support for fast and precise oil change processes.
Industrial Lubrication Systems: Ensuring oil supply for central lubrication systems.
Machine Maintenance: Transfer of general lubricants from tanks to points of use.
Gartec's wide product range offers supplementary solutions for every area of fluid handling. Besides the NP3001, it is worth exploring the following related products:
NP3008 Model: Electric vane pump with a capacity of 25 l/min for oil.
NP3010 Model: High-performance electric gear pump with 50 l/min capacity for oil.
NP3012 Model: Electric gear pump with 14 l/min capacity, equipped with a pressure switch for oil.
These accessory units allow users to precisely match the pump's performance to their specific flow requirements.
The NP3001 electric gear pump is a reliable 230V device that, with a flow rate of 9 l/min and a pressure of 11 bar, is an ideal choice for the efficient and controlled pumping of new oils. The 9 kg weight and 550 W motor provide an optimal balance between portability and sustained performance. Gartec is committed to quality fluid control technology, which this product also reflects.
