Part number: 881811
This high-quality extraction hood is specifically for the Caremaster mobile welding fume extractor and extraction unit of type VAS 892003A was designed, ensuring efficient and precise fume and dust capture during work processes. Wieländer+Schill's product offers a reliable solution for maintaining air quality, tailored to the demands of professional body repair and metalworking environments.
The extraction hood designed for the NW 150 extraction arm is a key component of the mobile extraction system, guaranteeing that harmful substances generated during heat treatment, welding, or cutting are immediately extracted at the source. The robust design and high-quality materials ensure a long service life and reliable operation.
Main Advantages:
Compatibility: Can be connected directly to the Caremaster mobile extractor and the VAS 892003A extraction and filtration unit.
Optimal Capture: Thanks to the wide opening, it is capable of efficiently capturing generated fumes and dust.
Adjustability: It allows for flexible positioning of the connected extraction arms, so the user can direct the extraction precisely where it is most needed.
Durable Material Use: Mainly made of plastic (kunststoff) elements, which provides low weight and resistance in the workshop environment.
The table below details the precise dimensions and material characteristics of the extraction hood:
| Property | Value | Note |
|---|---|---|
| Part number | 881811 | Unique Identifier |
| Connection Diameter (NW) | 150 mm | Nominal diameter of the extraction arm |
| Length | 265 mm | Outer Size |
| Width | 265 mm | Outer Size |
| Höhe | 345 mm | Outer Size |
| Material | Plastic (Kunststoff) | Durable and lightweight structure |
| Opening Size | 270 x 250 mm | The actual capture area |
This extraction hood seamlessly integrates into the ecosystem of Wieländer+Schill's professional extraction solutions. For efficient operation, it is compatible with the following systems, often used together:
The Caremaster is a mobile extraction and filtration unit designed for extracting and filtering fumes generated during the heat treatment and cutting of metals.
Configuration: It features an extraction arm with two internal joints.
Adjustability: Thanks to the new type of spring suspension, the extraction arms can be effortlessly adjusted to any position.
Extraction Hood: The extraction hood equipped with an integrated damper can be rotated in all directions, providing maximum flexibility.
This mobile extraction and filtration unit is specially optimized for capturing and filtering fumes and adhesive vapors generated during the heat treatment and separation of metals and plastics.
Effective Filtration Technology:
Pre-filter: A pre-filter mat captures the coarser dust particles.
High-Performance Particle Filter: Subsequently, it efficiently removes even the finest fumes and dust particles.
Filter Monitoring: An automatic filter monitoring system reliably indicates when the filters need cleaning or replacement.
Flexible Extraction System:
Arms: Two durable extraction arms equipped with internal joints ensure space-saving and unimpeded handling.
Mobility: Thanks to innovative spring assistance, the extraction arms can be easily adjusted to any desired position.
Maneuverability: The extraction heads equipped with a built-in throttle valve can be freely rotated in all directions.
Clean Air in the Workplace:
The purified air is returned directly into the workspace.
For applications involving adhesive vapors, an optional activated carbon filter can be used, which effectively binds gases and unpleasant odors, creating a safe and comfortable working environment.
Basic Accessories (for VAS 892 003A):
1 pc Activated Carbon Filter
1 pc Particle Filter F9
2 pcs Spark Arrestor Grate
1 pc Power Cable (5 m)
The NW 150 extraction head is the ideal choice for any industrial or workshop environment where localized extraction is required:
Welding Works: Extraction of fumes generated during MIG/MAG, TIG, spot welding.
Metal cutting: Capture of particles and fumes originating from plasma or flame cutting.
Soldering and Brazing: Removal of fumes and fine particles resulting from heat treatment.
Body Repair: Extraction of pollutants generated during underbody treatment, adhesive technologies, and other bodywork operations.
This extraction hood reflects Wieländer+Schill's commitment to high-level occupational safety and quality requirements, ensuring efficient and safe work execution.
