This detailed product description applies to the Wielander + Schill TCT Plus 90 mm saw blade (Part No: 197028), which was specifically developed for the most demanding body repair tasks, with particular attention to the precise and efficient machining of modern, high-strength steels.
A TCT Plus 90 mm Saw Blade belongs to the category of the latest generation separation tools, designed taking into account the most modern automotive requirements. The blade's advanced cutting geometry guarantees optimal cutting results even under the most difficult conditions.
This saw blade is excellently suited for processing all types of steel and alloys whose strength reaches 1800 MPa. This includes the latest generation high-strength materials such as USIBOR, BORON, BTR, HLE, TTHLE, and other ultra-high-strength steels.
One of the key advantages of using the TCT Plus blade is that during cutting, no hot sparks are generated, and the temperature of the cutting zone remains cool, so the structure of the metal is not changed near the cutting edge. This is critically important for preserving the integrity of high-strength steels.
For maximum service life and continuously optimal cutting performance the use of a suitable cutting lubricant is strongly recommended, especially when machining hard steels. Cutting oil is an excellent choice as it protects the saw blade from excessive heating.
This saw blade is specially optimized for processing high-strength steels . It is an ideal choice for cutting body elements where the precise, heat-free separation of high-strength materials is essential.
The table below summarizes the key technical parameters of the TCT Plus 90 mm saw blade:
| Property | Value | Note |
|---|---|---|
| Part number | 197028 | Unique Identifier |
| Típus | TCT Plus | Carbide Tipped (Tungsten Carbide Tipped) |
| Diameter (Length) | 90 mm | The actual length of the saw blade |
| Overall Dimensions (H x W x D) | 115 x 15 x 15 mm | Length x Width x Height (packaging or reference size) |
| Material composition | Hard Metal (Carbide), HSS, Metal | Teeth and blade material |
| Maximum Processable Hardness | 1800 MPa | Ideal for USIBOR, BORON, BTR, HLE, TTHLE materials |
| Field of application | Machining of high-strength steels | For special automotive applications |
| Thermal effect | No hot sparks, the cutting edge remains cool | Preservation of the metal structure |
The Wielander + Schill TCT Plus saw blade offers users numerous advantages during body repair processes:
Exceptional Material Compatibility: Specifically optimized for cutting the most modern high-strength and ultra-high-strength steels (UHSS), where conventional blades wear out quickly or cause overheating.
Temperature Control: Minimizing the heat generated during the cutting process ensures that the structural integrity of the cut material (e.g., hardness zones) is not compromised.
Safe Operation: The absence of sparking increases work safety, especially in enclosed spaces or near flammable materials.
Longer Lifespan: The use of high-quality carbide teeth and appropriate cooling/lubrication (with cutting oil) significantly extends the blade's lifespan, reducing downtime.
TCT (Tungsten Carbide Tipped) Technology: The carbide tips ensure durability and efficient cutting through hard materials.
To ensure the optimal performance and lifespan of the saw blade, the manufacturer recommends the following:
Cutting Lubricants: Always use a suitable cutting lubricant, especially when cutting materials with hardness exceeding 1000 MPa.
Cutting Oil: The use of cutting oil is an ideal solution as it effectively reduces friction and dissipates heat, thus preserving the saw blade's cutting capability.
This 90 mm TCT Plus saw blade is the cornerstone of the Wielander + Schill cutting tool portfolio, guaranteeing professional and reliable work in all areas of modern vehicle repair.
