This detailed product description presents a high-quality rivet die designed for the professional riveting technology of Wielander + Schill XSeries, essential for precise and reliable fastening tasks. The specially designed structure and superior material of the 4.5A type die guarantee efficient and durable performance.
A Mouthpiece 4,5A a special accessory used in Wielander + Schill XSeries systems, specifically for installing blind rivets. This die is a crucial element in the riveting process as it ensures the correct shaping and securing of the rivet head on the workpiece.
This model has a flat head and is ideally suited for 4.5 mm diameter blind rivets. Thanks to the precise fit and robust design, it contributes to the professional quality of automotive repair and semi-industrial work.
Compatibility:
This rivet die can only be used with the following Wielander + Schill blind rivet adapters:
BR 20 blind rivet adapter
BR 50 blind rivet adapter
When paired with the appropriate adapter, the 4.5A die provides optimal performance, ensuring a strong, standard-compliant connection.
The reliability and durability of the 4.5A die are guaranteed by carefully selected materials and strict manufacturing tolerances.
| Property | Value | Note |
|---|---|---|
| Part number | 700521 | Unique identifier for quick ordering and identification. |
| Internal Diameter (Ø) | 4.5 mm | Ideal for 4.5 mm rivet diameters. |
| Head Design | Flat head | Standard design for most applications. |
| Material | Steel | High-strength, wear-resistant steel construction. |
| Length | 12 mm | The total length of the die. |
| Width | 12 mm | The outer dimension of the die. |
| Höhe | 16.66 mm | The total height of the die. |
| Weight | 0.010 kg | Lightweight for fast and fatigue-free operation. |
| Package contents | 1 piece (1 stück, 1 piece) |
The 4.5A die is an integral part of the Wielander + Schill XSeries offering, representing the cutting edge of professional automotive repair technologies.
The flat head design ensures that the blind rivet head fits perfectly against the surface, minimizing damage and visual defects at the fastening point. The 4.5 mm inner diameter guarantees the precise centering and optimal deformation of the rivet mandrel during the pulling process.
The contact tip steel, manufactured, which provides exceptional resistance to high tensile forces and continuous mechanical stress. This robust construction significantly increases the tool's lifespan, thereby reducing maintenance and replacement part costs.
The modular nature of the XSeries systems was taken into account when designing the nose tip. Compatibility with BR 20 and BR 50 adapters provides flexibility for the workshop, allowing use with rivet guns of different performance levels and sizes without needing to change the nose tip between tool setups.
Weighing only 10 grams, this nose tip is extremely light. This feature is particularly important during long work sessions as it reduces operator fatigue and allows for more precise work, even in hard-to-reach areas.
The quality of the riveting largely depends on the appropriate pairing of the nose tip used with the type, size, and head shape of the rivet. The 4.5A nose tip (flat head, 4.5 mm) is the ideal choice when standard riveting on a flat surface is the goal.
Comparison with Other Items in the Range (Similar Articles):
Wielander + Schill offers a wide selection to meet various needs. In addition to the 4.5A model, other specialized nose tips are also available:
Nose Tip 4.0A (Part Number: 700520): With a flat head, for 4.0 mm rivets.
Nose Tip 4.8B (Part Number: 700522): With a concave head, 4.8 mm diameter, specifically recommended for RIBE blind rivets, usable with the BR 50 adapter.
Nose Tip 4.5B (Part Number: 700523): With a concave head, 4.5 mm diameter, also for RIBE rivets, with the BR 50 adapter.
Nose Tip 3.2C (Part Number: 700524): With a 3.2 mm diameter, specifically for riveting on roof gutter surfaces, with the BR 20 or BR 50 adapter.
The 4.5A nose tip thus provides an optimal, reliable solution for standard, 4.5 mm, flat-head rivets for professional users.
A Wielander + Schill Nose Tip 4.5A (700521) a precision steel component essential for efficient and durable blind riveting work in the XSeries riveting systems. Thanks to its flat head and 4.5 mm inner diameter, it guarantees a high-quality connection, while the steel material ensures a long lifespan even under the most intensive workshop conditions.
