Product Identifier: 311060
This 6-field temperature indicator strip is a cost-effective solution for high-volume use, especially for applications where space is limited. The product aims to indicate irreversible (non-reversible) temperature overshoots, which can be critically important in many industrial and body repair processes.
The indicator strip features a horizontal, six-digit scale in degrees Celsius (°C), which provides clear visual feedback on the degree of heating.
This temperature indicator is ideal for temperature monitoring tasks, especially during the preparation of aluminum parts, such as:
Pre-dent repair temperature monitoring: Ensures that aluminum parts do not exceed the permitted temperature limit before starting repair processes (e.g., shrinking, straightening).
Straightening works: Precise temperature monitoring during heat treatment processes to maintain material integrity.
Using the product minimizes the risk of heat damage, which is essential for high-quality and durable repairs, especially in the case of sensitive metal alloys.
The 6-point temperature indicator strip belongs to the category of Wieländer+Schill welding technology accessories and can be excellently integrated into existing workshop processes.
| Property | Value |
|---|---|
| Maximum indicated temperature | 160°C |
| Number of indicator points | 6 |
| Scale type | Horizontal, six-digit |
| Unit of Measure | Celsius degree (°C) |
| Material | Plastic (Kunststoff) |
| Dimensions (Length × Width × Height) | 34 x 12 x 1 mm |
| Package contents | 1 strip containing 10 measuring strips |
The design of the measuring strips is extremely thin (only 1 mm thick), which allows them to be applied even in tight spaces where other types of thermometers cannot be used. The markings irreversibly change when the strip reaches the set temperature value, so the fact and extent of heating are permanently recorded. This feature is particularly useful during quality assurance checks.
The plastic base material ensures adequate durability and protection of the temperature-sensitive layer under normal workshop conditions. The 10-piece strip is ideal for handling regular, high-volume parts.
Cost-Effectiveness: The 6-field design and strip packaging offer an optimal solution for high-volume, single-use temperature monitoring.
Space saving: Its extremely small dimensions (34 x 12 x 1 mm) allow it to be used even at critical points where space is limited.
Precise Temperature Monitoring: The indication of six consecutive temperature levels provides a more detailed picture of the temperature profile than single-point indicators.
Irreversible Indication: The permanent recording of a temperature overshoot provides reliable documentation on the adequacy of heat treatment.
Application: Specifically recommended for the temperature control of aluminum components in the body repair industry.
This product is part of the wide range of welding technology accessories from Wieländer+Schill, offering the precise tools needed for professional body repair.
