This high-quality arc flash resistant belt is the ideal complement to arc flash protected trousers, ensuring maximum safety and comfort in high-voltage working environments. The product has been designed and tested in compliance with strict safety regulations to provide optimal protection for workers.
The arc flash resistant belt with part number HV102110 belongs to the category of professional protective equipment from Wieländer+Schill, specifically developed for high-risk electrical work. During its design, great emphasis was placed on durability, wearing comfort, and fire protection properties.
Key Features:
Arc Flash Protection: The product is certified to be tested under arc flash conditions, thus providing reliable protection against sudden, high-energy electrical discharges.
Flame Retardant: The material composition ensures that the belt will not continue to burn if exposed to fire, minimizing the risk of injury.
Anti-static Properties: Prevents the build-up of static electricity, which is critically important in electrical work areas.
Permanently Elastic: Thanks to the special material blend, the belt retains its elasticity, ensuring a comfortable fit and freedom of movement for the wearer.
Durability and Maintenance: The belt can be cleaned with a normal washing process at 60 °C, which makes it easy to maintain hygiene requirements without compromising protective properties.
The table below details the exact specifications of the arc flash resistant belt:
| Property | Value | Note |
|---|---|---|
| Part number | HV102110 | Unique Identifier |
| Length | 110 cm | Also available in other sizes (100 cm) |
| Width | 38 mm | Standard workwear belt width |
| Color | Black | Universal color |
| Material composition (Textile) | 58% Polyester, 23% Modacrylic, 19% Cotton | Special protective blend |
| Buckle material | PA 6.6 | Polyamide 6.6 – high-strength plastic |
| Weight | 0.07 kg | Light to wear |
| Cleaning | Normal wash at 60 °C | Easy to maintain |
| Specification | Arc flash tested (im Störlichtbogen geprüft) | Complies with applicable safety standards |
| Package contents | 1 darab |
A combination of carefully selected materials has been used to achieve the protective effect:
Polyester (58%): Contributes to the tensile strength and dimensional stability of the fabric.
Modacrylic (23%): This component is primarily responsible for flame resistance and antistatic properties. Modacrylic fibers melt under heat but do not ignite, thus preventing the flame from spreading.
Cotton (19%): The natural fiber increases wearing comfort and improves breathability, which is essential during long working hours.
The material of the buckle, PA 6.6 (Polyamide 6.6), is extremely resistant and can withstand high mechanical stress and heat, ensuring reliable fastening of the belt.
This arc flash-resistant belt is essential equipment for all professionals working near high-voltage systems, including:
Electricians and maintenance technicians
Construction workers
Railway maintenance personnel
Operators of industrial facilities where there is a risk of arc flash
Wearing the belt alone is not sufficient; it must always be used together with complete protective clothing (jacket, trousers) appropriate for the specific work environment, which also features the same or a higher level of arc flash protection.
Wieländer+Schill is committed to the highest quality and safety standards. This product guarantees protection thanks to rigorous testing protocols. The manufacturer holds ISO 9001 (Quality Management) and ISO 14001 (Environmental Management) certifications, which further strengthens the reliability of the products.
Important note: The product is also available in a 100 cm length, but this model specifically offers the 110 cm size. Selecting the correct size is crucial for the protective effect to be valid.
