MICROFLEX™ Scale System (16,000 lbs / approx. 7257 kg)
The MICROFLEX™ 16,000 lb (approx. 7257 kg) scale system provides the highest level of accuracy and reliability for motorsports setup requirements. This robust, high-capacity system is ideal for precise axle weight and cross-weight measurements on heavier race cars, such as NASCAR, Pro Late Model, or other high-performance vehicles. Microflex technology guarantees consistent and repeatable results, which is essential for achieving maximum performance on the track.
Key Features and Advantages
This scale system combines the latest technology with the durability required for racetrack demands. The 16,000 lb capacity ensures that even the heaviest vehicles can be weighed accurately.
- Outstanding Capacity: The 16,000 lb (approx. 7257 kg) maximum capacity enables precise weighing of high-performance race cars.
- High Accuracy: Microflex™ technology provides extremely accurate and reliable weight data, which is critical for fine-tuning setups.
- Robust Construction: Designed to withstand the harsh conditions of the racetrack, ensuring long life and continuous performance.
- Compatibility: Although the raw text does not detail the display, the system is generally compatible with the manufacturer's advanced wireless and wired display systems (e.g.: SW777RFX™, SW787RFX™), enabling real-time data acquisition and analysis.
- Cross-Weight Adjustment: Allows for precise setting of weight distribution (left/right side weights), which is fundamentally important for optimizing vehicle handling.
Technical Specifications
Accurate technical data is essential for precise measurements. Although the input text does not contain all detailed specifications, the system falls into the following categories and can be fully customized with accessories offered by the manufacturer.
| Parameter |
Value |
Note |
| Maximum Load Capacity |
16,000 lbs (approx. 7257 kg) |
Ideal for heavy race vehicles. |
| System Type |
MICROFLEX™ |
Heavy-duty load cell technology. |
| Application Area |
Race car weighing |
Axle weight and cross-weight distribution. |
| Compatible Accessories |
Wide selection |
Includes displays, cables, and storage solutions. |
System Accessories and Ecosystem
The MICROFLEX™ 16,000 lb system integrates exceptionally well into the manufacturer's full range of measuring instruments, maximizing shop floor and trackside efficiency.
Related Scale Systems (Similar Capacity or Category)
Users often compare this system with other solutions offered by the manufacturer:
- MICROFLEX™ SCALE SYSTEM (8,800 lb): A lower capacity, but same-technology alternative for lighter vehicles.
- SW8.8k RFX™ WIRELESS SCALE SYSTEM: A wireless solution that combines Microflex accuracy with wireless freedom.
- SW888RFX™ WIRELESS SCALE SYSTEM: Another wireless option that can be adapted to user needs.
- SW777RFX™ WIRELESS PROFESSIONAL SCALE SYSTEM: A professional wireless system ideally suited for immediate transmission of weight data.
Accessories and Attachments
Accessories are essential for maintaining measurement accuracy and system portability:
Levelers and Storage
Perfect leveling of the scale pads is critical for accurate measurement.
- MICROFLEX™ SCALE SET-UP RACK: Special stand for quick and precise adjustment of weigh pads.
- BILLET SCALE PAD LEVELER: Precision leveling device for weighing pads.
- 2.5″ BILLET LEVELER WITH ROLL-OFF PAD: Leveler with a roll-off ramp that facilitates vehicle positioning.
- 4″ BILLET LEVELER WITH ROLL-OFF PAD: Leveler with a roll-off ramp for pads of 4-inch (approx. 10 cm) height.
- SCALE PAD LEVELER: General purpose leveler.
- ADJUSTABLE BILLET DRIVE-ON SCALE SETUP RACK: Adjustable drive-on weighing rack.
- QUIK RACK LIGHTWEIGHT SCALE RACK: Lightweight weighing rack.
- QUIK RACK LIGHTWEIGHT SCALE RACK – INCLUDES LEVELERS: Lightweight rack with built-in levelers.
Storage and Transport Solutions
For the protection of expensive and sensitive measuring equipment:
- SCALE PAD SYSTEM STORAGE CASE: Storage case for the complete weighing pad system.
- SCALE SYSTEM CARRYING CASE – FOR 4″ SCALE PADS: Carrying bag for 4-inch (approx. 10 cm) load cells.
- SCALE SYSTEM CARRYING CASE – FOR 2.5″ SCALE PADS: Carrying bag for 2.5-inch (approx. 6.35 cm) load cells.
- EQUIPMENT CASE (SMALL SIZE / MEDIUM SIZE): Bags for storing accessories of different sizes.
- PRECISION HUB PLATE SYSTEM CASE: Special case for precision hub-plate systems.
Other Accessories
- LASER LEVELING SYSTEM FOR SCALE PADS: Laser leveling system for maximum accuracy.
- THERMAL PRINTER: Thermal printer for immediate printing of measurement results.
- RECHARGEABLE 9 VOLT NICAD BATTERY / AA NiMH RECHARGEABLE BATTERY: Batteries for wireless systems.
Software and Data Management
For efficient processing of measurements, the system can be integrated with software solutions:
- RACEWEIGH SOFTWARE & WIRELESS NODE: The software package that enables the reception and analysis of wireless data.
- SW787RFX™ WIRELESS PC SCALE SYSTEM: A system specifically optimized for PC-based data processing.
Summary
The MICROFLEX™ 16,000 lb scale system is designed for professional motorsports where the accuracy of weight data directly influences the race result. The high load capacity, reliability guaranteed by Microflex technology, and extensive accessory ecosystem make this system one of the most reliable choices for standardizing and optimizing the weight setup process.
