This product description is intended for workshops and service centers, presenting a high-quality digital pressure gauge set ideal for the precise diagnosis and testing of hydraulic systems. The set combines the latest technology with a robust design, ensuring reliable and accurate measurements even in the most demanding industrial and automotive applications.
The Digital Pressure Measurement set is used for the quick and extremely precise measurement of pressure ratios in hydraulic systems. Compared to traditional analog instruments, this digital solution offers higher resolution and better readability, minimizing the possibility of human error during measurements. It is an ideal choice for testing complex hydraulic systems, such as high-pressure equipment, power transmission systems, or special industrial machinery.
The essential component of the set is the digital measuring instrument, which features an easily readable display and is capable of recording and analyzing measured values. The package includes the necessary adapters and connectors, enabling broad compatibility with various types of hydraulic couplings and pressure test points.
High Accuracy and Resolution: Digital technology guarantees the reproducibility of measurements and the detection of the smallest pressure fluctuations.
Robust Construction: Designed to withstand the rigors of the workshop environment, including vibration and environmental factors.
Simple Operation: Intuitive user interface and easily readable display that facilitates quick diagnostics.
Wide Application Area: Suitable for numerous areas, ranging from automotive hydraulics to construction machinery.
Integrated Functions: Possibility to record, store measured data, and potentially transfer it to a PC (exact functions depend on the specifications of the concrete model).
The set includes the necessary components for comprehensive testing of hydraulic systems. The table below summarizes the key technical parameters characteristic of the product line (Digital Pressure Measurement / Hydraulics diagnostic device digital).
| Parameter | Description / Value |
|---|---|
| Measurement Range | The exact range depends on the sensors, but generally includes standard operating pressures (e.g., 0-600 bar or higher). |
| Pontosság | High, typically ±0.5% FS (Full Scale) or better. |
| Display Type | Digital LCD/LED with backlight. |
| Connections | Various standard quick couplings and threaded adapters (e.g., BSP, NPT). |
| Tápellátás | Batteries or accumulators (depending on the instrument). |
| Housing Material | Reinforced plastic or metal housing. |
| Temperature Range | Operating temperature optimized for workshop conditions. |
| Data Management | Data logging and storage functions (optional). |
The package generally includes the following components, ensuring flexible use:
Digital Pressure Gauge Unit: The central measuring instrument, featuring a display and user interface.
Pressure Sensors/Probes: Sensors optimized for different pressure ranges.
Adapter Kit: Includes a wide selection of threaded and quick-connect adapters for connection to various hydraulic systems.
Carrying case: Robust, shock-resistant carrying case for safe storage and transport.
Connection Hoses: High-pressure, reinforced hoses for connecting the instrument and the tested point.
This digital measuring device is indispensable in the following areas:
In modern vehicles, hydraulic systems (power steering, braking system, transmission oil pressure) play a critical role. The digital set enables:
Transmission Oil Pressure Measurement: Checking the correct operation of automatic transmissions in various gears.
Brake System Testing: Precise checking of brake pressure, especially for commercial vehicles and special vehicles (Brake pressure testers for commercial vehicles, agricultural and OHW vehicles).
Air Conditioning and Refrigeration Systems: Although primarily focused on hydraulics, pressure measurement is also essential in the diagnostics of Cooling Systems and Air Conditioning systems.
Hydraulic systems form the backbone of heavy industry. With the help of the set:
Hydraulic Diagnostic Test Cases (Hydraulik-Test Case): The kit is ideal for complex troubleshooting where the cause of pressure fluctuations needs to be identified.
General Hydraulic Systems: Monitoring the pressure of pumps, valves, and cylinders to ensure maximum efficiency and lifespan.
Thermal management is also playing an increasingly important role in the field of electric and hybrid vehicles (Alternative Propulsion System / E-Mobility). Digital pressure gauges can be used for:
HV Battery Cooling: Monitoring the pressure of liquid-cooled systems (Thermal management Electric vehicles filling and testing equipment) to ensure safe operation.
Fuel Cell Systems: Monitoring the pressure of hydraulic components (Fuel cell units and fuel cell vehicles).
The digital pressure measurement set (Digital Pressure Measurement) represents a significant step forward compared to traditional analog instruments:
Objectivity: The digital display eliminates parallax errors that occur when reading analog gauges from an angle.
Data Logging: Ability to record dynamic pressure changes, which is essential for precise fault localization (e.g., transient pressure surges).
Unit Conversion: Fast and accurate switching between different pressure units (e.g., bar, psi, MPa) with a single button press.
Calibration and Maintenance: Modern digital sensors are often easier to calibrate, and the system provides feedback on the sensor's status.
This digital hydraulics diagnostic device (Hydraulics diagnostic device digital) is an indispensable tool for any professional who requires the highest level of accuracy and reliability when testing hydraulic systems.
