The ST BOX is a complete, ready-to-use diesel dispensing system designed with the highest level of safety and efficiency in mind. This unit, suitable for both mobile and fixed installations, integrates the pump, flow meter, filter, and all necessary accessories, all housed in a robust, lockable metal protective box. It offers an ideal solution for agricultural, logistics, mining, construction, and general industrial applications where reliable and controlled fuel transfer is required.
The ST BOX system is designed to be immediately ready for use with minimal installation requirements. The metal casing guarantees a long service life and provides secure storage in addition to physical protection.
Durable Structure: The entire system is protected by a solid, lockable metal box against external impacts, vandalism, and weather conditions.
Lockable Security: The lockable design of the box ensures that only authorized personnel can access the fuel, thereby reducing the risk of theft and unauthorized use.
Ready State: The system operates on a „Plug and Play” principle, ready for immediate installation on fixed or mobile tanks (suitable for both above-ground and underground tanks).
High Flow Rate: The built-in pump can deliver up to 85 liters/minute flow rate, enabling fast and efficient refueling even in high-traffic environments.
Precise Measurement: The mechanical flow meter provides the user with accurate feedback on the amount of fuel dispensed, aiding in invoicing and inventory management.
Antistatic Hose: The system is equipped with an antistatic fuel hose and an automatic dispensing nozzle for safe operation.
Guaranteed Filtration: The built-in a water-separating filter (Water Captor Filter) is essential for maintaining the quality of diesel and HVO fuels. This filter prevents harmful contaminants (especially water) from entering the vehicles' fuel systems, thus protecting the engines.
Alacsony Zajszint: During operation, the noise level is less than 75 dB, which allows the system to be used even in noise-sensitive environments.
The PRO version features an advanced electronic control unit, the Access 85-equipped, which provides full access control and fuel management.
User Identification: Access 85 enables access control using personalized user keys. The PRO version 4 pre-configured user keys includes.
Level Monitoring and Protection: With an optionally connectable level probe, Access 85 can monitor the fuel level in the tank. In case of low level, the system automatically prevents dispensing, preventing the pump from running dry and damaging the system.
Safety Timer: Access 85 has a 10-minute protection timer, which automatically shuts off the pump if it operates continuously for an extended period (10 minutes). This increases system safety and reliability.
PRO Extras: The PRO version includes the A60 automatic nozzle and water separator filter (WC Filter) is.
The ST BOX is available in various configurations that offer different performance and control capabilities. The table below summarizes the main specifications and the different available models.
| Product Code | Description | Pump Type | Flow Meter | Access Control | Filter |
|---|---|---|---|---|---|
| 00036700B | ST BOX E80 K33 A80 | Panther E80 | K33 | A80 (Electronic) | Not specified |
| F00365010 | ST BOX PRO PANTHER 72 K33 A60 WC FILTER | Panther 72 | K33 | A60 (Electronic) | WC Filter |
| F00365020 | ST BOX PANTHER 56 K33 A60 WC FILTER | Panther 56 | K33 | A60 (Electronic) | WC Filter |
| F00365050 | ST BOX E120 K33 A120 WC FILTER | Panther E120 | K33 | A120 (Electronic) | WC Filter |
| F0039900A | ST BOX BIPUMP 12V K33 A120 | Dual Pump (12V) | K33 | A120 (Electronic) | Not specified |
General Technical Parameters (Depending on configuration):
| Parameter | Details |
|---|---|
| Product Category | Fuel (Diesel/HVO/XTL) |
| Application Areas | Agriculture, Logistics, Mining and Construction Industry, Industrial use |
| Pump Flow Rate | Up to 85 l/min (model dependent) |
| Flow Meter Type | Mechanical (accurate measurement) |
| Noise Level | < 75 dB |
| Protective cover | Lockable metal box |
| Hose | Antistatic |
| Nozzle | Automatic dispensing gun (PRO version A60) |
| Filtration | Water separator filter (WC Filter) option available |
| Control (PRO) | Access 85 electronic access control system |
Due to the versatility of the ST BOX, it is the ideal choice for industries where on-site refueling is critical but requires strict control:
The ST BOX combines PIUSI reliability with modern fuel management needs, offering a compact yet full-value solution for the safe dispensing of diesel and HVO fuels.
