RFX Wireless Load Cell Beam for Racing Suspension with Indicator – (1 pc)
The RFX Wireless Load Cell Beam was developed for the precise execution of the highest level motorsport and vehicle dynamic adjustments. This wireless load cell beam is an essential tool for every professional who wishes to check and fine-tune the load distribution, spring rates, and suspension geometry of racing suspensions with the highest accuracy.
Modern racing technology demands reliable data acquisition in fractions of a second, and this wireless system provides exactly that freedom and precision. Overcoming the limitations of traditional wired solutions, this device enables engineers to check the vehicle under real-world conditions, outside of the measuring rig, thereby minimizing the possibility of installation errors.
Key Features and Advantages
The RFX Wireless Load Cell Beam combines the latest technology with a robust, racetrack-compatible design.
- Wireless Communication: Wireless data transmission provides freedom around the measuring points, eliminating the risk of accidents caused by cables and interference during measurement. This is especially advantageous in confined spaces or in cases of complex running gear geometries.
- Outstanding Accuracy: The device accurately measures the load acting on the suspension elements, which is essential for the optimal adjustment of symmetry and roll angles.
- Robust Construction: Designed to withstand the harsh conditions of the racetrack, ensuring long life and reliable operation.
- Simple Integration: Compatible with the latest RFX measuring systems and software, enabling seamless data acquisition and analysis.
- Quick Installation: Thanks to its wireless nature, setup time is significantly reduced, leaving more time for fine-tuning.
Technical Data and Specifications
Accurate technical parameters are essential for precise measurement. The table below summarizes the most important specifications of the RFX Wireless Load Cell Beam:
| Parameter |
Spezification |
Note |
| Measurement Principle |
Load Sensing Beam |
For measuring the force acting on the suspension points. |
| Communication |
Wireless |
For real-time transmission of the measurement. |
| Compatibility |
With RFX Billet Scale systems |
Full ecosystem integration. |
| Application Area |
Running gear load measurement, spring rate checking |
Ideal for racing cars and high-performance vehicles. |
| Construction |
High-strength materials |
Maximum durability and stability. |
| Data Transfer Rate |
High frequency, low latency |
Ensuring real-time feedback. |
| Power supply |
Internal, rechargeable battery (specifications according to the attached documentation) |
Long operating time for race days. |
The Importance of Accurate Measurement in Motorsport
The basis for adjusting the running gear is the precise knowledge of the load on the four wheels. With the help of the RFX Wireless Windicator, engineers are able to:
- Cross-Directional Load Optimization: The key to vehicle stability and cornering behavior is the balance of the load on the diagonally opposite wheels. The wireless rod allows for immediate identification of the smallest deviations.
- Spring Preload Check: The spring preload directly influences the ride height and the initial point of the spring travel. It allows you to precisely determine the force required to compress the spring to the desired extent.
- Dynamic Adjustments: Although the scale pad is intended for static measurement, measurements taken with wireless tools help understand how the running gear reacts to changes in load, even during the adjustment process.
System Integration and Accessories
This wireless load sensing rod does not operate independently but is part of the complete RFX measuring system. For maximum efficiency, the use of the following accessories and systems is recommended:
- Billet Scale Systems: The data can be ideally integrated with the displays and software of the SW777RFX™ Wireless Professional Scale System or other RFX measuring systems.
- Software: With the use of RACEWEIGH SOFTWARE AND WIRELESS NODE, measured data can be logged, analyzed, and compared with previous setups.
- Storage and Transport: To protect the precision tools, dedicated storage solutions are available, such as the SCALE PAD SYSTEM STORAGE CASE or the EQUIPMENT CASE (SMALL/MEDIUM SIZE), which ensure that calibration is maintained during transport.
- Leveling: To guarantee the accuracy of measurements, the use of the LASER LEVELING SYSTEM FOR SCALE PADS is recommended for perfectly leveling the measuring surface.
Summary
The RFX Wireless Load Cell Beam is a cutting-edge tool that forms the foundation for modern motorsport and high-performance vehicle setup. The wireless technology, outstanding accuracy, and robust construction guarantee that suspension adjustments are made according to the highest engineering standards. This investment directly contributes to optimizing vehicle performance and improving race results.
