This detailed product description presents the straight-jaw locking pliers from the Wieländer+Schill professional tool range, an ideal choice for precise and secure clamping tasks in automotive bodywork, metal processing, and general workshop applications.
This high-quality locking pliers (part number: 561156) has been specifically designed for clamping thick materials. The robust design of the tool and carefully selected materials guarantee a long service life and reliable performance even in the most demanding conditions.
The main advantages of the pliers include an adjustment screw, which allows for fine-tuning the jaw opening for different workpiece sizes, as well as a quick-release lever equipped with a return spring for quick and easy workpiece release.
For durability and reliability, the jaws of the pliers are forged, hardened, and nickel-plated, made from chrome-vanadium steel. This material selection ensures the tool's resistance to high loads and corrosion, providing optimal performance in the long run.
This tool is an essential device for every professional and DIY enthusiast who performs precise and secure clamping and holding tasks.
The table below summarizes the most important technical parameters of the locking pliers:
| Property | Value | Note |
|---|---|---|
| Part number | 561156 | Unique Identifier |
| Típus | Locking Pliers, with straight jaw | |
| Jaw Width (Maximum) | 40 mm | Maximum clamping capacity of the tool |
| Clamping range | 0 – 40 mm | Flexible adjustment of the clamping size |
| Length | 250 mm | Total length of the tool |
| Material | Steel | Base material |
| Jaws Material | Chrome - vanadium - steel | Forged and hardened |
| Surface Treatment | nickel-plated | Corrosion Protection and Increased Durability |
| Weight | 0.520 kg | Net weight of the tool |
| Package contents | 1 darab | Packaging Unit |
| Construction | With adjustment screw | For adjusting the jaw opening |
| Release | Quick release lever with return spring | Simple and fast workpiece release |
The built-in adjustment screw allows the user to adjust the jaw opening precisely to the thickness of the workpiece. This function is critically important for precision work where over-tightening or improper clamping could damage the component.
The mechanism, equipped with a quick-release lever and an integrated return spring, significantly speeds up the workflow. The tool can be released with a single motion, allowing the user to immediately reposition the clamp to the next fastening point, minimizing downtime.
The jaws, forged and hardened from chrome-vanadium steel, provide exceptional hardness and wear resistance. The nickel-plated coating not only lends an aesthetic appearance but also provides protection against moisture and corrosion caused by chemicals common in the workshop environment. The 250 mm length ensures an optimal leverage for secure fastening within the 40 mm clamping range.
This fixing clamp is excellently suited for:
Body Repair: Temporary or permanent fixing of components before welding, riveting, or gluing.
Semi-industrial tasks: Stable support for sheets, profiles, and other thick metal materials.
General assembly tasks: Any situation where one hand needs to remain free while the other hand's tool securely holds the workpiece.
This Wieländer+Schill product represents reliability and professional quality in the category of fastening tools.
