The Rotrix TSH-010 Diode and Rectifier Tester is a specially developed, professional instrument designed for reliable and fast checking of the diode bridges and individual diode performance in automotive generators. This device is an essential tool for any workshop dealing with the diagnostics and repair of generators, starter motors, or other electrical systems.
The purpose of the TSH-010 tester is to examine diode functions under simulated real operating conditions with alternating current, thus ensuring the most accurate condition assessment.
The Rotrix TSH-010 tester primarily provides indispensable assistance in the following areas:
Vehicle generators: Functional testing of the entire rectifier bridge (diode bridge).
Individual diode testing: Testing of a separate diode removed from the generator unit.
Fault Recognition: Quick identification of the causes and nature of diode failure.
The Rotrix TSH-010 has extremely detailed diagnostic capabilities and can identify the following problems:
Short Circuit: Immediate indication if the diode is in a short-circuited state.
Interruption (Interrupted): The diode circuit is interrupted; it does not conduct current.
Open Circuit: The diode is in a completely open state.
Diode degradation: The diode has lost its nominal characteristics, resulting in reduced performance.
Contact quality: Checks the quality of the contact between the diode and the conductor rails.
Avalanche diode identification: Capable of determining the type and characteristics of the avalanche diode, which is critically important for selecting the correct replacement part.
The TSH-010 tester offers a number of functions that simplify and speed up service work:
Realistic Test Environment: The diode testing is performed with alternating current, simulating the actual operating conditions of the generator, thus guaranteeing a reliable condition assessment.
Universal Compatibility: The device easily tests all types of rectifiers and diodes, regardless of their manufacturer or specification.
User-Friendly Operation: To use the instrument, the user does not need special, in-depth knowledge of diode parameters. The testing process is simple and intuitive.
Color-Coded Feedback: It communicates fault detections to the user with clear color signals, minimizing the possibility of misunderstandings.
Diagnostic Cable Testing System: The device is also equipped with a special system for checking diagnostic cables, ensuring the integrity of the entire test environment.
Compact Design: The small size of the tester allows for easy portability and convenient use in tight workshop environments.
For precise diagnostics, the Rotrix TSH-010 has the following technical parameters:
| Characteristic | Spezification |
|---|---|
| Product Category | Workshop Equipment, Testing and Measuring Devices |
| Brand | Rotrix |
| Model | TSH-010 |
| Tested Component | Automotive Diodes and Rectifier Bridges |
| Test Mode | Alternating Current (AC) Simulation |
| Fault Detection | Short Circuit, Interruption, Open Circuit, Degradation |
| Special Function | Avalanche diode identification, Contact quality check |
| User Interface | Indicators equipped with color signals |
| Construction | Compact, portable |
The Rotrix TSH-010 is part of Stremtec's wide range of workshop equipment portfolio, which includes the following:
Rotrix Testers and Tools: Besides the TSH-010, other special Rotrix testers are also available.
Autodiagger Test Equipment: Additional diagnostic tools.
EV/PHEV Diagnostic Equipment: Special equipment for electric and plug-in hybrid vehicles.
Other Workshop Equipment: Air conditioning testers, central lubrication units, paint booths, and industrial washing machines (Magido, Marwis).
The Rotrix TSH-010 is the ideal choice for every professional who requires reliable, fast, and detailed diagnostics for checking the rectifier systems of automotive alternators. Testing performed with alternating current guarantees that the tested component will function properly in the vehicle.
