SW777RFX™ PROFESSIONAL KART SCALE SYSTEM

SW777RFX™ Wireless Professional Go-Kart Weighing System

This detailed description of the SW777RFX™ Wireless Professional Go-Kart Weighing System (Accusative) introduces, which offers the highest level of accuracy and reliability for go-kart racers and mechanics. The system aims to make the measurement of the most critical setup parameters – axle load and total weight – extremely simple and precise, minimizing cable interference and setup time.

The SW777RFX™ is the perfect blend of engineering precision and wireless freedom, an essential tool for anyone seeking maximum performance on the track.

Key Features and Advantages

The SW777RFX™ system is designed to meet even the strictest competition requirements while providing intuitive operation:

• Wireless Technology: The integrated RFX® wireless transmitter units eliminate cable tangling and potential failure points common in traditional systems. This results in faster setup and a cleaner work area.
• Category Leading Accuracy: The system guarantees extremely high measurement accuracy, which is essential for fine-tuned chassis setup adjustments.
• Robust Construction: The load cells are made of durable, high-capacity aluminum that withstands the demands of the racetrack and various weather conditions.
• Simplified Data Transfer: The wireless connection stably transmits data to the display unit, ensuring real-time feedback on weight distribution.
• Go-Kart Specific Optimization: The size and load capacity of the load cells are specifically adapted to the unique needs of go-karts, ensuring optimal tire contact patch and precise measurement.

Technical Specifications

The technical specifications of the SW777RFX™ system guarantee professional performance:

System Components and Functionality

The SW777RFX™ is a complete solution that includes all the basic elements necessary for measurement, as well as advanced software capabilities (if the software package is also purchased).

1. RFX® Weighing Pads

The four scale pads are the heart of the system. These pads use the latest sensor technology to record even the slightest weight shifts.

• Integrated Transmitters: Each pad contains a built-in RFX® wireless transmitter. This ensures that the pads can be placed anywhere in the measurement area without being restricted by cables.
• Load Distribution: The smooth surface of the pads guarantees that the go-kart tires contact them with their full surface area, avoiding errors caused by point-load.
• Maintenance: The robust construction minimizes the need for calibration, but the system supports regular checking and calibration for maximum reliability.

2. Display Unit

The indicator unit is responsible for receiving, processing, and displaying the data.

• Real-Time Weight Display: Provides immediate feedback on the load on individual wheels (left front, right front, left rear, right rear).
• Total Weight Calculation: Automatically sums the data from the four pads to provide the total vehicle weight.
• Percentage Distribution: Capable of displaying the percentage distribution of weight between the front/rear and left/right axles, which is crucial for optimizing handling.
• Memory Functions: It is possible to store settings (e.g., base weight, set target values) for later comparison.

3. Software Compatibility (Optional)

Although the system can operate independently, for maximum analysis and data management, software integration is recommended (e.g.: RACEWEIGH SOFTWARE AND WIRELESS DOCKING STATION).

• Data Logging: Allows measurements to be recorded and tracked over time.
• Graphical Analysis: The software can visually display changes in weight distribution under various settings.
• PC Connection: Data can be forwarded to a PC via the wireless node for further analysis.

Application Areas and Advantages in Kart Racing

Setting the precise weight distribution is one of the most critical elements in karting. The SW777RFX™ system offers unparalleled assistance in this area:

1. Handling Optimization: Go-karts are sensitive to weight distribution. With the system, racers can set the desired ratio (e.g.: 45% front axle, 55% rear axle), which directly influences cornering ability and grip.
2. Quick Pre-Race Check: Thanks to the wireless design, the vehicle's weight can be quickly checked during warm-up or short breaks in the pit box, without the mechanics needing to spend time connecting cables.
3. Compliance with Regulations: Accurate total weight measurement is essential for meeting the minimum weight requirements of different categories.
4. Post-Part Replacement Calibration: After replacing wheel bearings, axles, or seats, the system can quickly be reset to previous settings or new target values.

Accessory Products and Maintenance

To maintain system performance and increase flexibility, several accessories are available (these are also available separately on the product page):

• Transport Solutions:
• SCALE PAD SYSTEM STORAGE CASE: Specially designed carrying cases for the safe transport of scale pads.
• SCALE SYSTEM CARRYING CASE – FOR 4″ SCALE PADS / 2.5″ SCALE PADS: Carrying cases adapted for different sizes of pads.
• Leveling and Spirit Levels:
• LASER LEVELING SYSTEM FOR SCALE PADS: Laser leveling system for the perfect horizontal alignment of the scale pads, which is a prerequisite for measurement accuracy.
• Kart Scale Levelers & Racks: Special levelers and storage stands for kart weighing scales.
• Power Supply:
• RECHARGEABLE 9 VOLT NICAD BATTERY / AA NiMH RECHARGEABLE BATTERY: Spare or auxiliary batteries to ensure long race weekends.

The SW777RFX™ Wireless Professional Weighing System represents the pinnacle of precision measurement in the world of kart tuning, ensuring every adjustment is made with the highest level of accuracy.
