This detailed product description presents the high-precision T5 Closing Die (Closing Die), which is part of the Wieländer+Schill professional bodywork specialist tool range, specifically designed for the professional and durable fastening of Self Piercing Rivets (SPR). This component belongs to the XSeries – Professional Riveting Technology product family, ensuring the highest level of performance and reliability during modern vehicle repair operations.
Product identifier for precise traceability and quick ordering: 700363. The tool is associated with the specification code KA0752113, which denotes the exact design and application area within the Wieländer+Schill internal system.
This closing die is a crucial element during the joining process using SPR technology. Its function is to precisely form the closing side of the rivet head, ensuring the professional and permanent connection of two or more layers of material (typically high-strength steels or aluminum alloys). The T5 design guarantees optimal force transmission and a closing head geometry conforming to standards.
Maximum Joining Quality: The precise design of the tool ensures that the SPR rivet's closing head obtains a perfect shape, which is essential for maintaining the structural integrity of the vehicle body.
Long Lifespan: Made from high-quality, wear-resistant materials that withstand high repetitive loads and continuous use.
Compatibility: Optimized for seamless integration with XSeries professional riveting systems.
Quick Change: Designed so that tool replacement on the riveting machine can be performed quickly and easily, minimizing downtime in the workshop.
The precise physical dimensions and specifications of the T5 closing die are as follows:
| Property | Value | Note |
|---|---|---|
| Part number | 700363 | Unique Identifier |
| Internal Code | KA0752113 | Product Family Specification |
| Típus | T5 Closing Die | For Self Piercing Rivets (SPR) |
| Length | 19 mm | Total length of the tool |
| Width | 19 mm | Main dimension of the tool |
| Höhe | 27.1 mm | Total height of the tool |
| Field of application | SPR Riveting | Forming the closing head of self-piercing rivets |
| Product Family | XSeries | Professional Riveting Technology |
This tool is indispensable in any body repair process where the use of Self Piercing Rivets (SPR) is required. SPR technology is crucial in modern vehicle manufacturing (especially for mixed-material structures) as it allows metal sheets to be joined without the need for pre-tapping threads, while ensuring excellent joint strength and vibration resistance. The T5 closing die guarantees that the rivet's closing side meets manufacturer specifications, which is critical for the correct functioning of the vehicle's passive safety systems (e.g., crash protection).
Wieländer+Schill is committed to the highest quality standards. Tool production takes place under strict quality control processes, which is supported by the company's ISO certifications:
ISO 9001: Quality Management System Certificate.
ISO 14001: Environmental Management System Certificate.
These certifications ensure that the T5 closing tool, item number 700363, is not only efficient but also reliable and responsibly manufactured from an environmental point of view.
This tool is designed for professional workshops where speed and flawless quality are both expected. The precise dimensions (19 x 19 x 27.1 mm) ensure compatibility with the appropriate riveting tools and machine holders. The T5 design allows for optimal deformation of the rivet head, which is the basis for the mechanical strength of the joint.
In summary: The 700363 T5 closing tool is a precision component that is an integral part of the Wieländer+Schill XSeries riveting technology, essential for the professional and durable fastening of Self-Piercing Rivets (SPR) used during body repairs.
