This product description refers to a high-quality, professional digital pressure gauge device, specifically developed for the diagnosis and monitoring of hydraulic systems. This instrument is an ideal choice for workshops, maintenance shops, and industrial facilities where precise and reliable pressure measurement is required.
Digital technology guarantees fast, accurate, and easily readable results, minimizing the possibility of human error compared to traditional analog gauges. The robust design of the device ensures durability even in the harshest workshop environments.
This digital pressure gauge device combines the latest technology with a user-friendly design to effectively measure the performance and integrity of hydraulic systems.
High Precision Measurement: The digital sensors provide extremely precise pressure readings, which is essential for ensuring the optimal operation of hydraulic systems and for quick fault identification.
Easy Readability: The large, well-lit digital display enables immediate and clear data retrieval even in poor lighting conditions.
Robust Construction: The housing resists mechanical stress, splashing fluids, and other challenges of the workshop environment, guaranteeing a long service life.
Wide Application Range: Specifically suitable for testing various hydraulic systems, including industrial machinery, construction equipment, and high-pressure systems.
Data Management Functions: Advanced models often feature data logging and storage capabilities, enabling documentation and later analysis of the measurements.
Simple Connection: Easily integrated into existing test rigs with universal connectors and adapters (available separately or as part of an included kit).
The table below summarizes the most important technical parameters of the digital pressure gauge device. (Note: Since the source material did not contain a specific model number or detailed technical table, the data below reflects typical specifications characteristic of the category, which should be supplemented with actual product data.)
| Parameter | Spezification | Note |
|---|---|---|
| Measurement Range | 0 – 600 bar (or according to the specific model) | Different pressure ranges available |
| Pontosság | ± 0.5% FS (Full Scale) | High level of reliability |
| Resolution | 0.1 bar / 1 psi | Fine resolution reading |
| Display Type | Digital LCD / LED | With backlight |
| Connection | G 1/4″ BSP or SAE O-ring | Industry standard connectors |
| Overload Limit | 150% from max. pressure | For the protection of the device |
| Temperature Range | -20°C – +60°C | Operating environment |
| Tápellátás | Internal battery (e.g., 3 x AA or Li-Ion) | Long operating time |
| Protection Class | IP65 or higher | Dust and splash-proof |
| Units of Measure | Bar, psi, MPa (selectable) | Flexible use |
This digital measuring device is indispensable in the following areas:
Hydraulic Diagnostics: Checking the pressure of pumps, valves, and cylinders under operating conditions.
System Calibration: Precise checking and fine-tuning of the setting points in hydraulic systems.
Troubleshooting: Quick localization of pressure leaks, leakages, or overpressure conditions in the system.
Quality Assurance: Performing final pressure tests after manufacturing or repair processes.
Although the exact contents of the kit are determined by the specific order code, digital pressure gauge devices generally contain, or are compatible with, the following components:
Digital Pressure Gauge Unit: The central measuring instrument.
Pressure Sensor: Sensor element connectable to the hydraulic system.
Connection Hoses: High-pressure, flexible hoses between the measuring unit and the test point.
Adapter Kit: Adapters for different threads and connections (e.g., NPT, BSP, metric).
Carrying case: Durable, protective bag for safe storage and transport.
Operating Instructions: Detailed description for installation, calibration, and operation.
Accessory Compatibility:
The product family (which includes hydraulic test kits, analog and digital diagnostic tools) offers a wide selection for workshops. This digital measuring device perfectly complements the Analog Hydraulic Test Kits (Hydraulik-Test Case, Analogue) and the Digital Hydraulic Test Kits (Hydraulik-Test Case, Digital), allowing the user to adapt the measurement method to the task.
The system can be further integrated with other testing devices from the offer, such as the Digital Pressure Measurement other special sensors in the (Digital Pressure Measurement) category, ensuring comprehensive diagnostic capability.
Compared to traditional analogue gauges with springs or diaphragms, the digital solution offers several advantages:
Memory and Recording: Digital devices are capable of recording the maximum and minimum pressure values during a measurement cycle, which is critical when examining dynamic systems.
Zeroing and Relative Measurement: It is possible to zero the pressure at any point, making it easy to measure pressure change or relative pressure.
Easier Calibration: Digital sensors often feature simpler, software-based calibration procedures compared to the more complex setup of mechanical instruments.
Longer Lifespan: Fewer moving mechanical parts reduce wear and the risk of accuracy degradation over time.
This digital pressure measuring device is a cornerstone of modern maintenance, increasing efficiency and ensuring the reliable operation of hydraulic systems.
