This detailed product description presents the excellent quality V2 closing die, which is part of the Wieländer+Schill professional bodywork specialist tools range, specifically designed for the professional and reliable fastening of solid self-piercing rivets. This component belongs to the XSeries – Professional Riveting Technology product family, ensuring the highest level of performance and durability during automotive repairs and semi-industrial applications.
The V2 closing die, part number 700277, is a precisely machined component essential for the proper closing of 4.0 mm diameter solid self-piercing rivets. The application of self-piercing rivets increases the strength of structures without the need for pre-drilling, significantly speeding up repair processes, especially for car bodies made from modern, high-strength steels.
This tool ensures that the rivet head is optimally formed and closed against the workpiece, ensuring a factory-quality, durable bond that resists vibration and load. The use of excellent quality materials in Wieländer+Schill tools guarantees a long service life, even with intensive, daily use.
Precise Rivet Closing: Optimized for 4.0 mm diameter solid self-piercing rivets, ensuring the creation of a perfect closing head.
XSeries Compatibility: Part of the XSeries professional riveting technology system, which guarantees compatibility with the appropriate riveting machines.
Excellent Material Quality: The tool is made from durable materials that withstand high mechanical stress and wear, minimizing the need for replacement.
Fast and Efficient Work Execution: Facilitates fast and repeatable, error-free riveting processes, increasing workshop efficiency.
OEM Compliance: The design and performance of the tool comply with strict OEM (Original Equipment Manufacturer) requirements, ensuring the preservation of body integrity.
The precise physical characteristics of the V2 closing die are as follows:
| Property | Value | Unit of Measure |
|---|---|---|
| Part number | 700277 | – |
| Product Name | V2 Closing Die for Solid Self Piercing Rivets | – |
| Compatible Rivet Diameter | 4.0 | mm |
| Length | 18 | mm |
| Width | 15.5 | mm |
| Höhe | 41 | mm |
| Product Family | XSeries – Professional Riveting Technology | – |
| Application | Closing Solid Self Piercing Rivets | – |
A V2 | Closing die for Solid Self Piercing Rivets (V2 | Closing die for Solid Self Piercing Rivets) is a special tool head that engages in the final phase of the riveting process. During riveting, the tool bears against the opposite side of the rivet, and under hydraulic or pneumatic force, it radially or axially deforms the end of the rivet, thereby creating a solid, durable connection between the two or more layers.
The design for 4.0 mm rivets ensures that the tool's indentation (the so-called „die cavity”) precisely matches the geometry of the rivet head, thus avoiding excessive material stress or improper closure. The external dimensions of the tool (18 x 15.5 x 41 mm) ensure compatibility with appropriate tool holders and riveting machine head holders.
Wieländer+Schill is committed to the highest quality standards. This product is also manufactured under the company's strict quality management system, proven to comply with the following international standards:
ISO 9001: Quality Management System Certificate.
ISO 14001: Environmental Management System Certificate.
These certifications guarantee that manufacturing processes are of consistent quality and that the product meets the latest industry requirements.
To maximize tool life, regular cleaning and inspection are recommended. Metal dust or debris accumulated on the tool surface can affect the quality of the closure. In case of tool wear, or if riveting results deteriorate, Wieländer+Schill offers service options for tool refurbishment or replacement, ensuring continuous professional execution.
This V2 closing die is a cornerstone of the Wieländer+Schill professional tool range, prioritizing reliability and precision in modern vehicle body repair technologies.
