XPress 800 | Tesla kit 1 | 3-piece

XPress 800 | Tesla Kit 1 | 3 Piece Kit

Part Number: 700020

The Wielander + Schill XPress 800 series represents the cutting edge of professional riveting technology. This specific, 3-piece Tesla Kit 1 (700020) is ideally suited for work involving high-strength structural elements, especially for the repair and maintenance tasks of Tesla vehicles where precision and high-force fastening solutions are required.

This kit contains the essential components of the XPress 800 modular riveting system, enabling the efficient and safe processing of parts made from difficult-to-access or extremely hard materials.

Product Description and Key Features

The XPress 800 system combines high-performance hydraulic technology with tool flexibility. The Tesla Kit 1 is specifically optimized for the most common Tesla-specific applications, ensuring fast and reliable fastening.

Main application areas:

• Setting Self-Piercing Rivets (SPR): The kit includes the necessary tool for applying SPR technology, which is essential for modern repairs of bonded and riveted body structures.

• Adapting Böllhoff tools: The included adapter allows for the integration of tools designed for Böllhoff systems with the XPress 800 unit, thereby increasing the versatility of the system.

• Large working range: The design of the C-arms provides a wide working range, facilitating access to various points on the vehicles.

The product is made from high-quality steel, guaranteeing a long service life and high load capacity even under the harshest workshop conditions. The surface treatment (blackened) increases corrosion resistance.

Technical Data

The table below details the main features of the kit and the specifications of the components contained within it.

Scope of Delivery Details

The XPress 800 | Tesla Kit 1 with part number 700020 is a carefully assembled, 3-piece package containing the following essential elements:

1. 1 pc 700071 C-Arm GC 80/120:

• This C-arm ensures the necessary distance and stability for riveting operations. The working range between 80 mm and 120 mm offers flexibility in handling different body thicknesses and placements. The designation „GC” refers to the geometric design, which enables optimal force transmission.

2. 1 pc 700443 F5 | Adapter for Böllhoff tools | 28 mm:

• This adapter is crucial for increasing system compatibility. It enables the connection of common 28 mm Böllhoff tools (e.g., dies) available on the market to the XPress 800 hydraulic unit. This feature can be particularly useful for repairs where an existing Böllhoff tool set is already available.

3. 1 pc 700260 E1 | Setting tool for Self-Piercing Rivets (SPR):

• This dedicated Setting die ensures the correct and complete installation of Self Piercing Rivets (SPR). The essence of the SPR technology is that the rivet pierces the lower sheet, then, by acting on the upper sheet, it spreads the end of the rivet, creating a mechanically solid, riveted joint, often in the case of aluminum and high-strength steels.

System Advantages in Tesla Repairs

Modern electric vehicles, such as Tesla models, utilize complex structures made of multiple materials (e.g., high-strength steels, aluminum alloys). Traditional welding processes can often damage adjacent materials or sensitive zones around the battery.

The XPress 800 system, and specifically the Tesla Kit 1 within it, offers the following advantages:

• Heat-Free Joining: SPR technology is a cold process, which minimizes thermal impact, thus preserving the integrity of adjacent materials (e.g., special coatings, adhesives).

• High Joining Force: The hydraulic force of the XPress 800 guarantees that the joint meets stringent safety and structural requirements, even for the hardest structural elements.

• Modular Capability: Although this kit consists of 3 elements, the XPress 800 platform allows for the addition of complementary elements from other kits (e.g., 70024, 70022), such as PushPull cylinders or C-arms of different sizes, so the tool kit can be adapted to the workshop's needs.

This kit is an ideal choice for professionals looking for specific, high-precision, and reliable riveting solutions necessary for repairing Tesla vehicles, without having to purchase the entire large-scale system.
