The LEITENBERGER Adapter for Hand Pumps (HAPA) series is specifically designed to allow users to perform pressure measurement or filling tasks precisely and efficiently, even in the tightest or most inaccessible locations. These high-quality accessories, manufactured in Germany (quality made in Germany), significantly increase the flexibility and applicability of HAP 02 and HDP type hand pumps.
The adapters simply replace the standard connector of the hand pump with the required HAP adapter (HAPA), ensuring a reliable 1/4″ connection. Leitenberger's engineering precision guarantees that the extended reach does not compromise measurement accuracy.
Optimized Access: Enables measurements in areas that would otherwise be inaccessible with conventional methods.
Simple Integration: Directly replaces the hose connection of the hand pump, with a standard 1/4″ connection.
German Quality: The product is manufactured in Germany according to Leitenberger's strict quality requirements, guaranteeing a long service life and reliability.
Diverse Designs: Variants of different lengths and angles are available to find the right solution for every unique installation situation.
The adapters can be classified into two main categories: straight (gerade) and angled (Winkeladapter) versions, as well as variants equipped with a special, integrated connector.
The connection point on every type 1/4″ size.
| Part Number (Bestell-Nr.) | Name (Beschreibung) | Típus | Length (Länge) | Diameter (Ø) | Note |
|---|---|---|---|---|---|
| HAPA_G 600/10 | Adapter gerade | Adapter straight | 600 mm | 10 mm | Long, straight reach |
| HAPA_G 200/10 | Adapter gerade | Adapter straight | 200 mm | 10 mm | Medium length, straight |
| HAPA_G 090/10 | Adapter gerade | Adapter straight | 90 mm | 10 mm | Short, straight reach |
| HAPA_G 130/06 | Adapter gerade | Adapter straight | 130 mm | 6 mm9.29" x 6.69" x 4.08" | Thinner diameter variant |
| HAPA_W 250/10 | 30° Angle Adapter | Elbow adapter 30° | 250 mm | 10 mm | 30 degree angled connection |
| HAPA_W 200/10 | 30° Angle Adapter | Elbow adapter 30° | 200 mm | 10 mm | 30 degree angled connection |
| HAPA_W 130/10 | 30° Angle Adapter | Elbow adapter 30° | 130 mm | 10 mm | Shorter 30 degree angle version |
| HAPA_SW 135/8 | 135° Short Angle Adapter | Elbow adapter short 135° | — | 8 mm | With integrated hose connection and coupling |
| HAPA_SD 180/8 | 180° Round Adapter | Round adapter 180° | — | 8 mm | With integrated hose connection and coupling |
A HAPA_SW 135/8 and HAPA_SD 180/8 The special advantage of these types is that these adapters already contain the necessary hose connection (Schlauchanschluss) and can be used directly with the supplied hose. This is an ideal solution for situations where flexible hose routing is essential for measurement. The 135° and 180° rotation ensures maximum maneuverability.
These adapters are indispensable in the following industries and applications:
Refrigeration and HVAC Technology: Pressure testing and filling in compact systems at hard-to-reach connection points.
Industrial Mechanical Engineering: Any process where the physical positioning of the hand pump prevents accurate work.
Maintenance and Service: Fast and efficient troubleshooting in tight engine rooms or inside equipment.
By using Leitenberger adapters, service technicians can save time, minimize installation difficulties, and ensure the reliability of measurements even under the most unfavorable conditions. The „Made in Germany” quality guarantees that the equipment will function precisely in the long term.
