This detailed product description presents the C10 type Closing Die, which belongs to the Wieländer+Schill XSeries professional riveting technology, specifically designed for the application of Self Piercing Rivets (SPR). This component is crucial for ensuring precise and reliable fastening processes during automotive repair and semi-industrial applications.
The C10 closing die is an essential accessory for Wieländer+Schill's professional riveting systems (XSeries). Specifically for the Self Piercing Rivets (Self Piercing Rivets – SPR) final closure. SPR technology is the basis for fast, strong, and heat-free connection of body parts, especially in the case of new generation high-strength steel and aluminum structures.
This tool ensures that the rivet head closes with optimal deformation, according to the specified parameters, thereby guaranteeing the mechanical integrity and durability of the joint. The precision design minimizes tool wear and ensures a long service life, even in high-traffic workshop environments.
Product identification and specifications are as follows:
| Property | Value |
|---|---|
| Item number | 700537 |
| Designation | C10 |
| Típus | Closing Die (Closing Die) |
| Application | Self-Piercing Rivets (SPR) |
| Ford Identifier | DP1002200 H1R1.5 |
| Length | 18 mm |
| Width | 18 mm |
| Höhe | 27 mm |
The design of the tool closely follows the Ford DP1002200 H1R1.5 specification. This coding denotes the precise geometric requirements for the riveting head closure:
DP1002200: Identifier for the rivet head size and type specified by Ford.
H1R1.5: This designation likely refers to the profile and depth of the closing surface (e.g., H1 for closing head height, R1.5 for radius or closure depth), which is critical for proper torque transfer and joint strength.
The tool dimensions (18 x 18 x 27 mm) ensure compatibility with the support systems of the appropriate riveting machines.
Wieländer+Schill components are manufactured according to the highest industrial standards, guaranteeing reliability and continuous performance.
The C10 closing die is manufactured with extremely tight tolerances. This precision is essential for the correct distribution of forces during the riveting process, preventing damage to the rivet or the workpiece.
Although the exact material composition is not included in the excerpts, tools of this type are generally made from extremely hard, wear-resistant tool steels, often with special heat treatment. This durability ensures that the tool can withstand high repetitive loads, reducing maintenance and replacement needs.
This tool has been optimized for the XSeries professional riveting technology platform. The modular structure of the XSeries systems allows for quick tool changes, and the C10 can be integrated quickly and securely into the appropriate riveting head or tool holder.
Self-piercing riveting is a cold-forming process where the rivet pierces the upper material, and then under the action of the tool, the lower end of the rivet deforms radially or axially, creating the solid connection.
The function of the C10 closing die is to counteract and form the lower end of the rivet. If the wrong tool is used, the following problems may occur:
Weak Joint Strength: Due to the incorrect closing profile, the rivet does not achieve the required clamping force.
Material Cracking: Uneven force distribution can cause cracks under the rivet head or on adjacent body panels.
Premature Tool Wear: Improper fit results in increased friction and rapid wear.
A Ford DP1002200 H1R1.5 precise adherence to its specification guarantees that the repair meets the manufacturer's requirements, which is particularly important for warranty and safety reasons.
The C10 closing die is part of the wider Wieländer+Schill offering, which includes the complete XSeries – Professional Riveting Technology range, including the appropriate Punches and Dies. This tool belongs to the „Dies | Punches | Extrusion Mandrels” category, representing essential components of the riveting process.
Wieländer+Schill's commitment to quality is also supported by the following certifications, ensuring that manufacturing processes and products comply with international standards:
ISO 9001: Quality Management System Certificate.
ISO 14001: Environmental Management System Certificate.
These certifications guarantee that during the manufacturing of the C10 closing die, strict quality control protocols are applied, ensuring consistent product performance.
A Part Number: 700537 The C10 closing die with this identifier is a precision, high-performance component essential for the professional and durable fastening of self-piercing rivets (SPR) applied to the bodywork of Ford vehicles. Compliance with the exact dimensions (18x18x27 mm) and the Ford specification (DP1002200 H1R1,5) ensures a professional repair result.
