The Consul 4.45 XLT-SN is an extremely robust and versatile four-post vehicle lift, specifically designed for lifting heavy-duty, long-wheelbase vehicles and for performing tasks requiring precise wheel alignment. It is an excellent choice for professional workshops where reliability, long service life, and broad functionality are essential.
This lift is ideal for lifting vehicles with a maximum permissible gross weight of 4,500 kg and for wheel alignment, particularly suitable for longer wheelbase models or dual-tire vehicles, thanks to its extremely wide and long platforms.
The Consul 4.45 XLT-SN lift incorporates several design elements that optimize work processes and increase safety:
Integrated Wheel Free Unit: The lift comes standard with a built-in wheel free lifting unit capable of handling loads up to 3,500 kg. This system features extendable supports for flexible positioning.
Master/Slave Hydraulics: The wheel free unit is equipped with a Master/Slave hydraulic system, ensuring stable and synchronized lifting during wheel alignment procedures.
Low Noise Hydraulics: The submerged, low-noise hydraulic drive contributes to a more pleasant working environment.
Electro-hydraulic Control: A modern and reliable electro-hydraulic control system ensures precise operation.
Safety Features: The lift is equipped with several safety features, such as acoustic foot protection, a hydraulic tensioning cylinder, protection against slack cables, cable failure protection, and anti-rollback protection.
Easy Drive-On: The platforms are equipped with 1000 mm long drive-on ramps, which are also ideal for sporty, low-profile vehicles.
Securing Options: One platform is equipped with a nearly fully adjustable securing mechanism. An integrated rail is available for the jacking beam.
Pneumatic Central Locking: The central control operates with a pneumatic locking system (at 8 bar pressure). Locking is ensured via safety rods in 100 mm increments over the entire lifting height.
CE and GS Certification: The lift complies with GS (Geprfte Sicherheit) and DIN EN 1493 standards and holds CE certification. Its protection class is IP 54.
Optional Column Distance: Upon special request, the distance between the columns can be extended to 3,000 mm (optional item).
The following table details the critical technical parameters of the Consul 4.45 XLT-SN lift:
| Parameter | Value | Note |
|---|---|---|
| Rated load capacity | 4.500 kg | Total lifting capacity |
| Lifting height | ca. 2.005 mm | Maximum lifting height |
| Lifting Time (loaded) | approx. 35 seconds | |
| Set-up width | 3,250 mm | |
| Drive-up height | approx. 145 mm / approx. 195 mm (AM) | AM: optional installation height |
| Clear distance between columns | ca. 2.780 mm | Default setting |
| Tápellátás | 400 V / 50 Hz | Three-phase power supply |
| Drive Power | 3.0 kW | |
| Fuse Protection | 16 A slow-blow | |
| Oil quantity | 9 liters | |
| Incline width | 500 mm | |
| Incline length | 5,500 mm | |
| Incline distance (adjustable) | kb. 980 – 1.190 mm | |
| Overall height | ca. 2.660 mm | |
| Total length with approach ramps | ca. 6.660 mm | |
| Drive-over height | approx. 50 mm (SN) | SN: Only the height of the ramp |
| Wheel-free lift load capacity | 3,500 kg | |
| Wheel-free lift lifting height | ca. 450 mm | |
| Wheel-free lift length | 1,400 – 1,900 mm | Extendable supports |
| Wheel-free lift lifting time | 15 seconds |
If the lift is ordered together with the wheel alignment set, the following functions become available:
Integrated Full-Size Sliding Plates: Sliding plates built into the platforms enable the lateral movement required for wheel alignment.
Turntable System: The set includes a system for turntables, which can also be used for turntables up to 50 mm high, with a sequential turntable cover.
The 4.45 XLT-SN model can be flexibly extended according to the specific needs of the workshop:
Column Distance Extension: It is possible to increase the distance between the columns to a clear width of 3,000 mm (for the 4.45 series).
Auxiliary Lift: Available in galvanized finish with blasting (at extra cost), which provides additional lifting points.
Complete Wheel Alignment Set: Complete set for lifts equipped with wheel-free lift, with 500 mm platform width and 5,500 mm platform length.
Adapters for 3D Wheel Alignment Systems: Special adapters for retrofitting, for example for Beissbarth Easy 3D systems (1 set = 2 pieces).
Sliding Plate Retrofit: Accessory sliding plate set for retrofitting, for lifts with a low platform.
Anti-Slip Coating: Anti-slip coating for drive-on ramps (ATTENTION: this coating cannot be retrofitted).
Drive-on/Drive-off Ramps: Drive-on/drive-off ramps (with abrollsicherung) for lifts with flush installation, without runway restriction equipment (1 set = 2 pieces).
The Consul 4.45 XLT-SN lift is the result of reliable German engineering, guaranteeing long-term, problem-free operation even under the most intensive workshop conditions.
Product Identifiers:
SKU: 559310
HAN: 421678
Category: 4-Post Lifts
