This excellent quality, floor recessible lift belongs to the Consul professional workshop equipment category, specifically designed for the Twin Ram Inground Lifts series. The product ensures maximum flexibility and wide vehicle compatibility for modern servicing.
The design of the symmetrical, roller-guided telescopic lifting arms allows for safe and efficient lifting of various vehicles, from smaller Smart models up to long-wheelbase (up to 4,325 mm) Crafter/Sprinter types. This lift is ideally suited for 2.55 MKK type lifting systems.
This equipment is the result of precision engineering, prioritizing durability, safety, and ease of handling:
Roller Guide Telescopic Arms: The arms, equipped with roller guides, ensure extremely smooth and precise movement across the entire extension range.
Four-part, Triple-stage Extendable Arms: This design provides exceptional flexibility and numerous pick-up points, optimizing access for vehicles of different wheelbases and sizes.
Symmetrical Design: The symmetrical arms guarantee optimal weight distribution and stability when lifting heavy loads.
Arm Locking Device: The built-in arm locking mechanism increases safety during lifting and operation by preventing accidental displacement of the arms.
Robust Load-bearing Surface: The lifting platforms are fitted with a hard rubber profile that protects the vehicle chassis from damage while ensuring stable contact.
Fine Adjustment Capability: The height of the arms can be adjusted using a threaded spindle with an approximate 30 mm stroke, enabling perfect alignment even on uneven floor conditions.
Complete Installation Kit: The package includes the necessary installation materials for the professional installation of the lift.
Quality Assurance: The product has GS (Geprüfte Sicherheit) certification, complies with DIN EN 1493 standard, and has CE certification, guaranteeing adherence to the highest industrial safety requirements.
The following table details the critical technical parameters of the Consul 2-ram lift:
| Characteristic | Value | Note |
|---|---|---|
| Rated load capacity | 5,500 kg | Maximum safe load capacity. |
| Lifting height | approx. 2,185 mm | The maximum lifting height of the vehicle. |
| Under-clearance | ca. 120 mm | The distance between the floor and the lower part of the lift (in the recessed position). |
| Long arm extension range | approx. 700 – 1,690 mm | Total working width of the four-piece arms. |
| Distance between columns | 2,500 mm | The internal distance between the two main support columns. |
| SKU (Item Number) | 659508 | |
| HAN (Factory Number) | 475382 | |
| Category | Twin Ram Inground Lifts | Twin-cylinder in-ground lifts. |
This chassis is ideally suited for the 2.55 MKK lift models. For maximum flexibility and adaptation to special vehicles, Consul offers a number of accessories compatible with this model type:
Tailored to service needs, the following accessories can significantly expand the lifting capabilities:
Consul Spacer Shims 100 mm: Set of 4 pieces for Consul swing arm lifts with a load capacity exceeding 4,500 kg.
Consul Spacers 12 mm: Set of 4 pieces, compatible with Consul swing arm lifts with a load capacity exceeding 4,500 kg.
Consul Spacer Shims 150 mm: Set of 4 pieces, compatible with Consul swing arm lifts with a load capacity exceeding 4,500 kg.
Consul Spacer Shims 200 mm: Set of 4 pieces, compatible with Consul swing arm lifts with a load capacity exceeding 4,500 kg.
Consul Spacer Sleeves 50 mm: Set of 4 pieces, compatible with Consul swing arm lifts with a load capacity exceeding 4,500 kg.
Consul Pickup Support from 4.5 t: Pickup adapter specifically recommended for off-road vehicles. 1 set = 2 pcs. For swing arm lifts starting from 4,500 kg and caravan lifts (including 2.65 EL models).
A detailed technical description and installation guide are available for the product:
Catalogue: A detailed brochure is available in PDF format, containing further information about the C-Line twin-cylinder chassis.
Installation Manual: Available for professional installation.
This Consul chassis offers the perfect blend of reliability, high load capacity, and the necessary adaptability to serve modern vehicle fleets for professional automotive service environments.
