This product is part of the Wieländer+Schill XSeries professional riveting technology, a tool specifically designed for the precise machining of solid rivets (SR). The D11 type punch and forming tool is an ideal choice for bodywork and metalworking tasks where creating a reliable and durable joint is essential.
The D11 punch and forming tool is designed to effectively punch and form 4.0 mm diameter solid rivets (SR). This tool ensures the optimal shape of the rivet head, guaranteeing a professional and durable fastening even in the most demanding applications. Thanks to precision manufacturing, the tool offers a long service life and consistent performance.
This tool is designed for professional body repair shops where quality and precision are fundamental requirements. The reliability of Wieländer+Schill products and compliance with strict quality specifications are also supported by ISO 9001 and ISO 14001 certificates.
The main features and specifications of the D11 punch and forming tool can be found in the table below:
| Property | Value | Note |
|---|---|---|
| Part number | 700827 | Unique identifier for quick ordering and identification. |
| Application | Punching and Forming | For solid rivets (SR). |
| Compatible Rivet Diameter | 4.0 mm | Can only be used for 4.0 mm diameter solid rivets. |
| Length (L) | 18 mm | The total length of the tool. |
| Width (W) | 18 mm | Overall width of the tool. |
| Height (H) | 42 mm | Overall height of the tool. |
| Series | XSeries | Belongs to the Wieländer+Schill professional riveting technology family. |
| Típus | D11 | Tool with a defined geometry. |
The D11 tool is manufactured with extremely tight tolerances, which is essential for the proper setting of solid rivets. Its geometry, optimized for 4.0 mm rivets, ensures that the rivet head takes on the desired shape and size during the riveting process, maximizing the mechanical strength of the joint.
Wieländer+Schill tools are made from high-quality, high-strength steel alloys that resist high mechanical stress, wear, and fatigue. This durability guarantees that the tool will maintain its original profile over the long term, thereby reducing the frequency of replacement and maintenance costs.
This tool has been developed for the XSeries professional riveting technology platform. This system has a modular structure, enabling quick tool changes and flexible adaptation to different riveting tasks. The D11 tool integrates perfectly into the system, ensuring efficient and fast work performance.
The physical dimensions of 18 x 18 x 42 mm ensure that the tool is compatible with the holder systems of the corresponding riveting machines while providing sufficient material thickness to achieve the required strength.
The D11 punch and forming tool is primarily used in the following industries and applications:
Automotive Industry: Solid riveting of body parts, chassis components, and other structural elements, especially during repair and refurbishment work.
Mechanical Engineering: General metal construction and assembly tasks where riveting is preferable to welding (e.g., when joining dissimilar materials).
Structural Engineering: Fastening of smaller metal structures where vibration resistance and durability are crucial.
Wieländer+Schill is committed to the highest quality standard. Production processes are strictly monitored, which is reflected in the following certificates:
ISO 9001: Quality Management System certification, which guarantees consistently high product quality.
ISO 14001: Environmental management system certificate, verifying sustainable manufacturing practices.
This tool is the ideal choice for professionals seeking reliable solutions that comply with OEM recommendations for the professional machining of 4.0 mm dowel pins.
