Product Identifier: 700246
This professional tool set, belonging to the Wieländer+Schill XSeries – Professional Riveting Technology product family, is specifically designed for setting and forming solid rivets (SR) with a diameter of 4.0 mm. The set contains high-quality, precision-machined tools that guarantee reliable and durable connections during body repair work.
The D8 + D9 tool set consists of two essential components that work together to ensure the optimal setting of solid rivets. The design of the tools ensures proper material deformation during the formation of the rivet head, thereby maximizing the strength and durability of the connection.
Main area of application: Setting of Solid Rivets (Solid Rivets – SR), especially in areas requiring a durable fastening subjected to high mechanical stress.
The set with part number 700246 contains the following elements:
| Quantity | Part number | Designation | Function |
|---|---|---|---|
| 1 stück | 700813 | D8 Closing tool for solid rivets (SR) | Tool responsible for forming the rivet head. |
| 1 stück | 700811 | D9 Closing tool for solid rivets (SR) | Tool for forming the blind side of the rivet. |
This tool is a critical element in the rivet setting process. The D8 tool is responsible for creating the final shape of the rivet head during the riveting process. Precise machining ensures that the formed head meets solid riveting standards and provides an optimal contact surface between the fastened parts.
Goal: Forming the closing head of solid rivets (SR).
Compatible Rivet Diameter: 4.0 mm.
Advantage: Long-lasting, wear-resistant design.
The D9 tool operates in parallel with the D8, typically applied to the blind side of the rivet to provide the necessary pressure and forming. This tool ensures that the rivet mandrel expands appropriately and fastens the components, preventing loosening and movement.
Goal: Forming and securing the blind side of solid rivets (SR).
Compatible Rivet Diameter: 4.0 mm.
Advantage: Excellent fit with the D8 tool for perfect symmetry.
Wieländer+Schill tools are manufactured according to the highest quality standards, ensuring the precision required for professional body repair.
| Parameter | Value | Note |
|---|---|---|
| Product Family | XSeries – Professional Riveting Technology | High-performance tools |
| Product Type | Tool Set (Die Set) | Closing and Counter-tools |
| Part number | 700246 | Identifier of the complete kit |
| Application | Setting Solid Rivets (Solid Rivets – SR) | Material Forming and Fastening |
| Rivet Diameter | Ø 4 mm | Calibrated exactly to this size |
| Accessory 1 (D8) | Part number: 700813 | Locking tool |
| Accessory 2 (D9) | Part number: 700811 | Counter tool |
| Quality Assurance | Supported by ISO 9001 certification | Quality of manufacturing processes |
By using the D8 + D9 tool set, professionals can enjoy the following benefits:
Maximum Joint Strength: The precise cooperation of the two tools guarantees that the solid rivet fully exerts its fastening capability in its dimension, which is essential for safety-critical body elements.
Material Machining Accuracy: The design of the tools minimizes unnecessary stress in the surrounding material while ensuring the aesthetic and functionally correct shape of the rivet head.
Compatibility and System Integration: The set is part of the XSeries professional riveting systems, ensuring seamless integration with existing Wieländer+Schill equipment.
Durability: The tools are made of high-quality steel, resistant to high repetitive loads and wear, which reduces tool replacement costs in the long run.
This tool set is fundamentally important for any repair shop that uses the highest level of body repair technologies, especially regarding the application of solid rivets on structural elements of modern vehicles.
