Offered by Wielander + Schill PSP GT single-sided spot welding gun the InvertaSpot GT an extremely versatile and functional tool developed for welding machines. This gun is the ideal choice for car body repair work, especially where access in tight spaces is limited. Thanks to its design, it is exceptionally light and handy, which significantly increases user comfort and work efficiency.
The main strength of the PSP GT gun lies in its modular design, which allows for quick and easy replacement of various welding tips. This flexibility ensures that the appropriate dent repair technique (e.g., welding of pulling tabs, rivets, or T-studs) can be optimally adapted to the body parts.
The PSP GT gun was designed with the needs of professional automotive repair shops in mind:
Lightweight and Handy Design: Minimizes user fatigue during prolonged operation and allows for more precise control.
Excellent Accessibility: Due to its compact dimensions, it makes hard-to-reach areas on the vehicle body easily accessible.
Multifunctionality: Thanks to the exchangeable contacts, it is suitable for supporting numerous spot welding and pulling techniques.
System Integration: Optimized specifically for the InvertaSpot GT welding system.
Durability: Robust construction that guarantees a long service life even in intensive workshop environments.
The table below details the specifications of the PSP GT single-sided spot welding gun:
| Parameter | Value | Note |
|---|---|---|
| Part number | 478006 | The product identifier. |
| Típus | Single-Sided Spot Welding Gun | PSP GT |
| Compatibility | InvertaSpot GT | Connection to the welding machine. |
| Length (cable) | 2.5 m | Length of the ground cable. |
| Overall Dimensions (L x W x H) | 2700 x 40 x 160 mm | Dimensions of the gun and connections. |
When purchasing the product, the package contains the following items:
1 × Single-sided Spot Welding Gun GT with handle (SK-22): The main welding unit, equipped with an SK-22 type electrode holder.
1 × Ground cable with electrode holder (D-25): Grounding element required for closing the correct circuit.
1 × 478002 Accessory Box: A storage unit containing selected accessories for the PSP GT single-sided spot welding gun.
Numerous special accessories are available to utilize the full potential of the PSP GT gun and perform various repair tasks. These accessories allow for the optimization of welding spots and the increase of pulling process efficiency.
| Part number | Product Name | Description |
|---|---|---|
| 490007 | Electrode, copper, PSP GT | Air-cooled copper electrode, specifically for the PSP GT gun. |
| 497015 | Electrode for washers | Special electrode for welding pulling tabs on body parts. |
| 497019 | Electrode for T-studs (Ø 3-5 mm) | Electrode for fixing T-studs for the PSP GT gun. |
| 497021 | Electrode for welding studs | Double-sided electrode: one side for 2.0-2.5 mm, the other side for 4 mm diameter studs. |
| Not specified | Electrode for welding studs (5 & 6 mm) | Separate electrode for 5 mm and 6 mm diameter welding studs. |
497028 Tabs (copper plated, Ø 8/16 mm, 100 pcs/PU): Copper-plated tabs for dent repair.
497025 Welding nut M8 (25 pcs/PU): For creating threaded fixing points.
297013 Triangle-shaped pulling tabs (15 pcs/PU): These, together with the quick-pull hammer, enable fast and economical repair. Worn or burnt tips can be easily re-filed if necessary.
497010 Copper paste for electrodes (75 g): Measurably reduces transient resistances and improves the conductivity capability of the electrode arms, ensuring stable welding quality.
298298 Electrode cleaner (Grit size 60): Exclusively clean electrode tips guarantee correct spot welding results. This device is used for cleaning contaminated electrode caps.
478100 Quick Pull Hammer Set for InvertaSpot GT: This set is optimized for the PSP 60 welding gun and the InvertaSpot GT.
Scope of delivery:
1 pc 501025 Universal slide hammer
1 pc 501033 Electrode for triangular pulling attachments (M14)
1 pc 501034 Hook attachments (M14)
1 pc 297009 Washer (DIN 125, Ø 8.4/16 mm, 100 pcs/PU)
1 pc 297013 Triangular pulling attachments (15 pcs/PU)
475012 GT Grip (SK-22): Grip for the single-sided GT gun with holder.
475013 GT Grip (For Ground Cable D-25): Grip equipped with the holder for the ground cable D-25.
The PSP GT single-sided spot welding gun is a key element of the Wielander + Schill welding technology portfolio, which raises the speed and quality of body repair processes to a new level thanks to interchangeable tips.
