Part number: 497019
This high-quality T-stud electrode is specifically designed for single-sided spot welding guns from Wieländer+Schill, especially for the PSP GT type. This component is essential for the precise and reliable welding of T-studs during body repair work, ensuring professional fitment and a durable connection.
This electrode belongs to the category of professional body repair technologies, as part of spot welding technologies. Welding T-studs is a critical procedure that enables the restoration of damaged panels without the need for access points on the backside of the body. The electrode's design guarantees that the T-stud ensures optimal contact with the workpiece during the welding process, minimizing heat impact and deformation.
The product is the ideal choice for any technician using Wieländer+Schill welding equipment and aiming to meet the highest quality standards.
The table below details the key technical characteristics of the electrode that determine its performance and compatibility:
| Property | Value | Note |
|---|---|---|
| Part number | 497019 | Unique identifier for quick ordering. |
| Application | T-stud welding | Exclusively for welding T-studs. |
| Compatibility | PSP GT single-sided spot welding gun | Optimized specifically for this model. |
| Diameter (Internal) | approx. 9 mm | The critical dimension for T-stud seating. |
| Length | 55 mm | The overall length dimension. |
| Width | 21.5 mm | The cross-sectional dimension. |
| Höhe | 21.5 mm | The cross-sectional dimension. |
| Material | Copper-zirconium (CuZr) | Excellent electrical conductivity and high heat resistance. |
| Weight | 0.079 kg | Lightweight for ease of handling. |
| Package contents | 1 piece (1 stück) | Single packaging. |
The electrode is made of copper-zirconium alloy, which is a premium material considered standard in spot welding technology. The use of this material comes with the following benefits:
Excellent Electrical Conductivity: Ensures minimal resistance, enabling fast and efficient current transfer at the welding spot.
High Heat Resistance and Wear Resistance: The addition of zirconium increases the material's strength at high temperatures, significantly extending the electrode's lifespan, even under intensive use.
Shape Stability: Maintains its precise geometry throughout the cycles, which is essential for consistent weld quality.
By using the T-stud electrode with article number 497019, users can benefit from the following advantages:
Precise T-Stud Positioning: The precisely designed internal diameter (approx. 9 mm) ensures that the T-stud is held firmly on the electrode tip, which is crucial for achieving an accurate weld spot.
Longer Lifespan: The copper-zirconium composition reduces rapid wear and erosion of the electrode, thus requiring less frequent replacement, lowering downtime.
Optimized Welding Performance: Compatibility with the PSP GT gun guarantees that welding parameters (current, time) are applied optimally, resulting in excellent weld strength between bodywork elements.
Easy Maintenance: Standard dimensions and quality materials facilitate the cleaning and profiling of the electrode according to the manufacturer's specifications.
This part is part of the broad portfolio of professional body repair tools from Wieländer+Schill, reflecting a commitment to quality, reliability, and long-term performance. The product belongs to the Welding Technology and among the Resistance Spot Welding category.
