Gartec proudly presents the Electric gear pump with NP3012 part number, specifically designed for the reliable and efficient dosing of new oils. This robust unit, operating on a 230V mains voltage, provides an ideal solution for central oil distribution systems where precise dosing and high operating pressure are required. The built-in pressure switch automates operation, increasing system efficiency and safety.
The NP3012 model is a high-performance, electrically driven gear pump optimized to handle the viscosity of new oils, ensuring continuous and even flow. A maximum flow rate of 14 liters/minute and an operating pressure of 12 bar make it possible to deliver the fluid efficiently to the desired points, even over longer distances or in systems with higher resistance.
The pump's 750 W motor operates at 1450 revolutions/minute, creating an optimal balance between performance and lifespan. The noise level of 77 dB is considered acceptable in its category, especially considering the high-pressure operation.
Optimized for Central Distribution Systems: The built-in pressure switch enables automatic control, which is essential in modern, automated maintenance systems.
Reliable Performance: The gear design guarantees the constancy of fluid delivery, minimizing pulsation.
Powerful Operation: The 12 bar operating pressure is sufficient for most industrial and workshop applications.
Egyszerű Telepítés: It features a standard 230V mains connection, and both inlet and outlet connections are designed with 1 inch thread (thumbs) for easy integration.
This pump has been specifically designed and recommended for the transfer of the following fluids:
The detailed technical parameters of the NP3012 pump can be found in the following table:
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | NP3012 | – | Gartec Identifier |
| Flow Rate | 14 | l/perc | Maximum Capacity |
| Operating pressure | 12 | bar / PSI | Maximum pressure |
| Supply Voltage | 230 | Volt (V) | Mains voltage |
| Power | 750 | Watt (W) | Power Consumption |
| Rotational speed | 1450 | rev/min (rpm) | Motor Speed |
| Noise Level | 77 | dB | Operating noise level |
| Inlet connection | 1 | inch (thumbs) | Suction side size |
| Outlet connection | 1 | inch (thumbs) | Discharge side size |
| Weight | 15 | kg | Net Weight |
| Packaging size | 350x280x280 | mm | Box Dimensions |
The NP3012 electric gear pump is an ideal choice for environments requiring reliable, high-volume new oil dispensing:
Vehicle Service Stations and Workshops: Connected to central systems where vehicles need to be quickly and accurately filled with fresh engine oil.
Industrial Maintenance: In lubrication supply systems of machines and equipment.
Automated Lubricant Dosing: In processes where the pressure switch ensures automatic shutdown of the system upon reaching the desired pressure.
The mechanical construction of gear pumps is extremely robust. The two interlocking gears seal precisely, allowing for the transfer of fluid from the suction side to the pressure side while minimizing internal leakage (internal backflow). This design ensures the maintenance of high pressure, which is essential for efficient distribution.
The pump housing and internal components are resistant to oils, ensuring a long service life and minimal maintenance requirements. The weight of 15 kg lends stability to the unit, while the compact packaging size (350x280x280 mm) facilitates shipping and installation.
The Gartec NP3012 electric gear pump is a combination of reliability, performance, and automation. With a flow rate of 14 l/min and a pressure of 12 bar, along with the built-in pressure switch, this 230V unit is an indispensable tool for any facility requiring efficient and controlled distribution of new oils.
