The Wielander + Schill WPS 3000 is a handy, extremely powerful, and quietly operating professional body saw, specifically designed to meet the demands of modern vehicle repair. This pneumatic tool is excellently suited for the precise and efficient separation of body elements while minimizing strain on the user and the environment.
A standout feature of the WPS 3000 saw is its extremely low vibration level, which, according to ISO 8662, is only 2.5 m/s². This feature significantly reduces the noise level, which is thus only 77.4 dB(A) (according to ISO 15744), and allows for continuous, uninterrupted operation of the device without operator fatigue or degradation of the working environment quality. The device also complies with the health and safety regulations of the Employers' Liability Insurance Association (Berufsgenossenschaft).
A 10 mm stroke length guarantees excellent cutting performance, ensuring clean and fast material removal even in the toughest applications. Thanks to the pneumatic drive, the saw operates reliably in workshops where the air quality meets the ISO 8573-1 standard.
Ergonomic and Powerful: Compact design, high power (300 W) and easy handling.
Exceptionally Quiet Operation: The noise level of 77.4 dB(A) significantly contributes to a more pleasant working environment.
Low Vibration: Less than 2.5 m/s² vibration, which reduces the risk of Hand-Arm Vibration Syndrome and increases user comfort in the long term.
Designed for Continuous Operation: Robust construction for use in professional, high-demand workshop environments.
Versatile Cutting Capability: Thanks to the wide selection of interchangeable saw blades, it is suitable for cutting almost any body material.
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | BMWA9500836 | – | BMW OEM recommendation |
| Power | 300 | W | |
| Operating pressure | 6 – 8 | bar | |
| Stroke | 10 | mm | Long stroke length for efficient cutting |
| Stroke Speed | 12000 | /min | |
| Noise level (sound pressure level) | 77,4 | dB(A) | According to ISO 15744 |
| Vibration | < 2.5 | m/s² | according to ISO 8662 |
| Dimensions (L x W x H) | 1150 x 63 x 42 | mm | |
| Materials | Alu, Aluminum, Plastic, Steel, Kunststoff | – | |
| Air quality | ISO 8573-1 | – |
A variety of special bi-metal saw blades are available for the WPS 3000 saw, which optimize cutting according to the specific material thickness and type:
| Teeth per inch (tpi) | Material recommendation | Field of application |
|---|---|---|
| 14 tpi | Bi-metal | Wood, aluminum, composite materials, and GRP (glass-fiber reinforced plastic) |
| 18 tpi | Bi-metal | Narrow radius cuts, dashboard work |
| 24 tpi | Bi-metal | Sheet metal thickness combinations up to 4 mm |
| 28 tpi | Bi-metal | „Hybrid materials” (aluminum-steel, GRP) |
| 32 tpi | Bi-metal | Thin sheet metal and high-strength steels up to 1 mm thickness |
The WPS 3000 air saw is fully equipped, ensuring immediate operational readiness:
To maximize efficiency and tool lifespan, we recommend using the following accessories:
1. Saw blade M42 18 tpi, 100mm, bi-metal (Part No.: BMWA9500725) This premium saw blade is specifically designed for the precise machining of longitudinal chassis beams found in vehicle construction. The newly developed tooth geometry prevents rapid clogging of the cutting teeth and in many cases allows for direct plunge cutting into the sheet metal without pre-drilling. The increased material thickness enhances stability during the cutting process, ensuring accurate straight-line cutting.
2. Saw blade 32 tpi, bi-metal (Pack of 10) (Part No.: BMWA9500731) Universal saw blade for thin sheets, up to 1.2 mm thickness. Ideal for fitting new parts.
3. Saw blade 24 tpi, bi-metal (Pack of 10) (Part No.: BMWA9500732) For double and triple sheet metal thicknesses, up to 4 mm. Especially suitable for load-bearing structures. Excellent for use with HSS, ZStE, DP steels, and TRIP steels.
4. Saw blade 28 tpi, bi-metal (Pack of 10) (Part No.: BMWA9500738) Newly developed saw blade specifically designed for hybrid material joints (e.g., aluminum-steel, GRP, and plastics). Ideal for glued body structures, as the innovative toothing effectively prevents cutting teeth from clogging.
5. Saw blade 14 tpi, bi-metal (Pack of 10) (Part No.: BMWA9500741) For aluminum, wood, composite materials, and GRP.
1. Tool holder, gray (Part No.: 124027) Usable for all saws in the series: WPS 3000, WPS 2000, WPF 3000, PS 1, PLF 90, PLF 80, DKS 100, PS 8.
2. Pressure reducing valve, 7 bar (Part number: 194000) Excessive operating pressure in pneumatic tools can lead to premature wear and damage. This cost-effective, yet essential solution for every workshop prevents tool damage, thus ensuring their longer lifespan. Recommended for all body saws.
3. Compressed air mini oiler (1/4″) (Part number: 637103) The mini oiler reduces wear on pneumatic tools with a 1/4″ connection and improves their handling. The device has a window design, which helps prevent sticking or clogging of individual pneumatic components due to over-oiling.
