This detailed product description focuses on a key element of the Wieländer+Schill professional body repair tool range, the brass-plated wire brush, which is specifically designed for the fine machining, cleaning, and preparation of bodywork components. It is ideally suited for tasks where precision and surface compatibility are both essential.
This brass-plated steel bristle wire brush is the ideal choice for cleaning welding seams, removing rust, and preparing paint and lacquer layers without damaging the base metal of the workpiece. The brass plating ensures that the brush does not spark and is gentler to the base metal, which is particularly important when working on sensitive surfaces such as aluminum or thinner steel sheets.
The product belongs to the Dent Removal Technology & Metalworking (Dent Removal Technology and Metal Processing) category, including from the Body Panel Repair belongs to the (Body Repair) section, and Scraper | Deburring Tools | Brushes strengthens the (Scrapers | Deburring Tools | Brushes) subgroup.
This wire brush is manufactured according to the quality standards of Wieländer+Schill, guaranteeing a long service life and reliable performance even in the most intensive workshop environments.
Perfect Cleaning: The 0.3 mm diameter brass-plated steel wires are ideally suited for removing surface contamination, oxidation, and welding slag without leaving deep scratches on the surface.
High Speed Capability: The brush can be safely used at a maximum speed of up to 24,000 revolutions/minute (U/min), enabling fast and efficient work.
Universal Thread: The M6 threaded connection ensures compatibility with most standard electric hand tools and drives.
Kompakt Méretek: The 36 mm diameter and 6.5 mm width make it ideal for reaching tighter areas and more complex shaped body panels.
Durable Construction: Made of steel base material, coated with brass, which increases corrosion resistance and the flexibility of the wires.
The precise specifications of the product ensure the selection of the appropriate tool for the intended task.
| Property | Value | Note |
|---|---|---|
| Part number | 541214 | Unique identifier for ordering and identification. |
| Design | Wire Brush | |
| Coating | Brass-plated | For surface treatment and spark-free operation. |
| Material | Steel | The base material of the wires. |
| Bristle wire diameter | 0.3 mm | For fine-grained cleaning. |
| Diameter (Ø) | 36 mm | The total working width of the brush. |
| Width | 6.5 mm | The thickness of the brush. |
| Connection | M6 thread | Standard threaded mounting. |
| Maximum Rotational Speed | 24,000 RPM | For professional, high-speed applications. |
| Overall dimensions (Length x Width x Height) | 42 x 42 x 15 mm | Brush full coverage. |
| Weight | 0.020 kg | Lightweight for fatigue-free work. |
| Package contents | 1 piece (1 stück) |
To achieve optimal performance of the brass-plated cup brush, it is recommended to observe the specified maximum speed (24,000 rpm). Always fasten the tool securely to the M6 arbor of the drive unit.
Application areas:
Preparation of welded seams: Removal of weld slag and oxidation, especially on sensitive surfaces.
Removal of paint and lacquer layers: Gentle grinding that prepares the surface for priming or repainting.
Corrosion Protection: Removal of surface rust and deposits without significantly altering the metal structure.
Cleaning of metal surfaces: General cleaning tasks where conventional steel brushes would be too aggressive.
This 36 mm brass brush is part of the extensive Wieländer+Schill range, serving the highest demands in body repair, ensuring precise and durable results. The product perfectly complements the company's other metal processing and deburring tools.
