Intercomp low profile, medium capacity aircraft scales offer an excellent solution for precise weight and center of gravity determination in aircraft where space-saving and easy handling are crucial. These systems are ideal for use at airports, maintenance bases, and hangars where the installation of traditional, large-sized weighing systems is impractical.
The robust design and precise sensors of the scales guarantee reliable and repeatable measurements, ensuring the safe operation of the aircraft and correct setting of the center of gravity (CG).
These weighing systems are designed to meet the highest industry standards, combining portability with high accuracy.
Low Profile Design: The extremely low profile minimizes the need for ramps, making it easier to position the aircraft's landing gear on the weighing surfaces. This significantly reduces setup time and the risk of accidents.
Medium Capacity: Ideal for most small and medium-sized general aviation (GA) and some light commercial aircraft.
High Accuracy: Intercomp scales are renowned for their exceptional accuracy, which is essential for complying with strict aviation regulations.
Modular and Portable: The system can be easily disassembled and transported, ideal for mobile maintenance crews or for measurements conducted at various sites.
Wireless Connection: Modern systems often support wireless (RFX®) communication with display units, increasing flexibility and reducing cabling issues.
Integrated Center of Gravity Calculation: Compatible displays and software (e.g., ACWeigh™) can automatically calculate the center of gravity based on the measured axle and wheel weights.
Low-profile, medium-capacity aircraft scales can be categorized into the following main categories, for which Intercomp offers a wide selection:
These weighing units can be placed directly under the landing gear, and typically the following models belong to this category:
| Model | Characteristic Capacity (Per Wheel/Total) | Profile Height | Application Area |
|---|---|---|---|
| AC15-LP™ | Medium range | Very Low | General aviation purposes |
| AC40-LP™ | Medium-high range | Low | Smaller commercial and business aircraft |
| AC60-LP™ | High capacity low profile | Low | Larger mid-size aircraft |
Further Platform Systems:
ACII™ Aircraft Weighing System: A complete, integrated solution that includes the platforms and the central CPU.
AC30-60™ High Capacity Scale: Although higher capacity, it can be used with low-profile systems for fine-tuning weight distribution.
These systems can be integrated with hydraulic or mechanical jacks used to lift the aircraft, thus measuring the weight at the lift points.
Jack Weigh AC100™ Kit: A reliable, medium-capacity lifting scale kit.
Jack Weigh EZ RFX® Kit: An extremely flexible lifting scale solution utilizing wireless technology, ideal for quick field measurements.
These kits are particularly useful for aircraft where placing a platform under the wings or tail section is difficult.
Precise display units are essential for processing measurements and calculating the center of gravity (CG):
TAC30™ CPU – Touchscreen Indicator: Modern, user-friendly interface providing real-time data processing and display.
RFX® Wireless Handheld Indicator: A flexible, portable display that allows the operator to monitor measurements from a safe distance.
RFX® Wireless AC100™ Aircraft Scale CPU: A wireless hub specifically optimized for the AC100™ Jack Weigh system.
ACWeigh™ Software: Dedicated application for recording and archiving measurements, and for performing center of gravity (CG) calculations.
iACWeigh™: A version optimized for mobile devices, which increases flexibility during on-site work.
Low-Profile Mid Capacity Aircraft Scales provide critical support in the following specialized aviation areas:
The development of electric vertical take-off and landing (eVTOL) vehicles presents extremely strict weight and balance requirements. Compact, high-precision scales are ideal for testing prototypes where every gram of weight distribution matters.
For periodic inspections of smaller single- and multi-engine piston, as well as turboprop aircraft, where determining the center of gravity is essential for safe fuel and load distribution.
Due to the easy deployment of the scales, they are ideal for hangars where different types of aircraft often need to be weighed without installing a permanent, built-in weighing system.
Intercomp systems are excellently suited for For Certified Weight & Balance Training (Certified Weight & Balance Training), as they provide real, measurable data for participants.
To maintain the accuracy of the weighing systems, Intercomp provides comprehensive support services:
CSM™ Manual Test Stand: A simple but effective tool for periodic checking and calibration of load cells.
CSA™ Automated Test Stand: A fully automated calibration system that enables fast and documented verification to meet the highest accuracy requirements.
These calibration systems ensure that the Low-Profile Mid Capacity scales always comply with the tolerances prescribed by aviation authorities.
Intercomp's Low Profile Mid Capacity Aircraft Scales offer the perfect combination of reliability, accuracy, and flexibility to meet modern aerospace requirements.
