Part number: 561021
This professional, mechanical punch pliers, with a 5 mm hole diameter, has been developed specifically for bodywork and vehicle repair tasks. The tool operates extremely smoothly, requiring minimal physical effort for precise work, thus significantly increasing efficiency in the workshop environment.
The punch pliers are the ideal choice for situations where precise holes are needed in sheet metal, especially when preparing for MIG-MAG or TIG welding processes. Creating clean, burr-free holes is essential for quality joining and maintaining the structural integrity of the bodywork. This tool is a practical device for every modern workshop and body repair technician.
Smooth Operation: Thanks to the mechanical design, the tool runs extremely smoothly, requiring minimal physical exertion during use, which reduces user fatigue in the long run.
Precise Hole Preparation: Specifically designed to create precise and clean 5 mm diameter holes in metal sheets.
Welding Preparation: Ideal preparation tool for hole welding (MIG-MAG, TIG), ensuring optimal positioning of weld points and damage-free preparation of the sheet metal.
Durable Material Use: Manufactured using high-quality HSS (High-Speed Steel) and steel, guaranteeing long service life and consistently reliable performance.
Ergonomic Design: Its compact dimensions (230 mm length) and optimal weight (0.350 kg) allow for comfortable and safe handling.
Detailed specifications for the product can be found in the table below:
| Property | Value | Note |
|---|---|---|
| Part number | 561021 | |
| Type of Operation | Mechanical | |
| Hole Diameter (Punch Hole Ø) | 5 mm | Dimensions of the punch tool |
| Clamping range (Clamping range) | 0 – 0.8 mm | Maximum sheet metal thickness on which the tool can be effectively applied |
| Work window (Work window) | 2 – 20 mm | The optimal operating size range of the tool |
| Length | 230 mm | Total length of the pliers |
| Dimensions (L x W x H) | 220 x 105 x 36 mm | The external dimensions of the tool |
| Material | HSS, Steel | Main structural materials of the tool |
| Weight | 0.350 kg | Easy handling |
| Package Contents | 1 darab | Unit removal |
This mechanical punch pliers is an essential tool for the following areas:
Vehicle Body Repair: Ideal for preparing connection points when replacing or repairing damaged sheet metal.
Sheet Metal Processing: General workshop applications where fast and precise holes need to be made in thinner metal sheets.
Welding Preparation: Precise creation of holes required for hole welding, which increases the quality and durability of the weld seams.
Tools manufactured by Wieländer+Schill represent reliability and professional quality in the field of body repair technologies. The 5 mm punch plier is the perfect combination of durability and ease of use.
