The Leitenberger MG6F, MG8F, and MG1F pressure gauges are high-quality instruments designed for front mounting, specifically developed for the accurate measurement of high and low pressures in refrigeration and air conditioning systems. Guaranteeing „Made in Germany” quality, these manometers deliver reliable performance even in the most demanding industrial and service environments.
These instruments are ideal for the inspection, maintenance, and servicing of refrigerant systems, ensuring accurate pressure reading thanks to the scale optimized for various refrigerants.
The MG6F/MG8F/MG1F series pressure gauges combine durability and precision:
Excellent Quality Design: The instrument housing is made of stainless steel (INOX), which provides excellent resistance to corrosion and mechanical stress.
Glycerin-Filled Structure: The internal structure is filled with glycerin. This filling significantly dampens pressure fluctuations and vibrations, thereby stabilizing the pointer movement and increasing the instrument's service life.
Color Scale: The measuring dials feature a colored scale, which facilitates the quick and error-free identification of the optimal pressure ranges corresponding to different refrigerants.
Front Mounting: The design allows for the simple and safe installation of the instruments into measuring blocks or switchboards.
High Accuracy: The 1.6 accuracy class guarantees the reliability of the measurement results.
The table below details the specifications of the MG6F/MG8F/MG1F pressure gauges:
| Property | Spezification |
|---|---|
| Type Number | MG6F / MG8F / MG1F |
| Application | Measurement of high and low pressure in refrigeration systems |
| Measuring Scale | bar / psi (dual scale) |
| Accuracy Class | 1.6 |
| Housing Material | INOX (Stainless Steel) |
| Connection | Brass, rear connection |
| Thread Dimensions | 1/4″ SAE, 1/8″ NPT or 1/2″ BSP (optional) |
| Filling | Glycerine |
| Display | Colored scale for refrigerants |
| Fixation | Suitable for front mounting |
These pressure gauges are essential tools in the refrigeration sector:
The devices are ideal for monitoring the pressure ratios of compressors, condensers, and evaporators. The colored scales help professionals quickly check if the system is operating within the appropriate operational parameters for the specific refrigerant (e.g., R134a or natural refrigerants). Glycerine damping is particularly useful in systems where pressure can change suddenly.
Due to their high reliability and precise 1.6 class, the MG6F/MG8F/MG1F models can be built into industrial measuring stations requiring continuous and accurate pressure monitoring. The various thread types (SAE, NPT, BSP) ensure wide compatibility with existing systems.
The large display providing easy readability and the dual bar/psi scale facilitate on-site work. The robust INOX housing guarantees that the instrument will withstand the frequent physical impacts common in service environments.
Leitenberger Mess- und Regeltechnik GmbH is committed to manufacturing excellent quality measuring instruments. The MG6F/MG8F/MG1F series is the result of German engineering expertise, ensuring long-term, trouble-free operation. The products undergo strict quality control to meet the highest industrial standards.
Product Identifier: MG6F/MG8F/MG1F
