This professional punch plier is an excellent quality tool optimized for body repair work, especially for MIG welding preparations. It enables the precise and fast creation of an 8 x 20 mm oval (elongated) hole, significantly speeding up workflows.
By eliminating the need for traditional double-hole drilling, this tool creates the ideal connection surface required for welding in a single step, thus increasing work efficiency and the quality of the final bond.
This punch is an ideal choice for preparing body panels where weld points need to ensure optimal overlap.
Fast and Easy Handling: Specifically designed so that the preparation of body panels for MIG welding can be done quickly and easily.
Simplified Preparation: Eliminates the need for previously required, time-consuming double drilling.
Material Compatibility: Excellent for use on „steel 37” type sheet materials.
High Accuracy: Creates precise 8 x 20 mm oval holes.
Robust Construction: Made from durable materials ensuring a long service life.
The detailed specifications of the tool ensure compliance with the requirements for professional use:
| Property | Value | Note |
|---|---|---|
| Part number | 561003 | |
| Hole Type | Stanzlangloch (Oval hole) | |
| Hole Size | 8 x 20 mm | Punch Size |
| Maximum Sheet Thickness | 1.5 mm | For steel sheets only (max. 1.5 mm) |
| Material | HSS, Steel | High-strength tool steel and steel construction |
| Total length | 320 mm | Total length of the pliers |
| Dimensions (L x W x H) | 340 x 85 x 41 mm | External dimensions of the tool |
| Weight | 2.200 kg | Solid, stable design |
| Work opening (Work window) | 2 x 30 mm | Tool gripping/working area |
| Field of application | Body repair, preparation for MIG welding | |
| Compatible material | Steel type 37 sheet |
The oval punch tong with part number 561003 is an essential tool for modern automotive repair. When repairing body panels, it is often necessary to fix two sheets together by welding, which ideally requires an oval overlap opening.
This tool allows you to create the necessary connection point on the parts to be welded with a single, clean cut. The advantage of the oval shape is that it allows for greater tolerances when fitting the sheets, and it ensures optimal material overlap for the weld seam, which increases the strength of the repaired joint.
The 320 mm long arms provide sufficient force to cut through 1.5 mm thick steel sheet, while the tool's weight (2.2 kg) guarantees stability during precise positioning. The HSS (High-Speed Steel) parts guarantee the durability and resistance of the cutting edges to high loads.
This tong is the ideal choice for any professional looking to maximize the speed and quality of body repair processes, especially during jobs requiring a large number of welding points.
