The PIUSI PICO is an extremely versatile and robust fluid transfer unit, specifically designed for dispensing diesel, HVO/XTL fuels, as well as windscreen washer fluid and antifreeze. It offers an ideal solution for agricultural and industrial applications where a reliable, easy-to-install, and manageable pump is required.
The central element of the PICO unit is the centrifugal pump, which ensures fast and efficient fluid movement. Its compact dimensions and low weight (up to approx. 6 kg) allow for flexible installation in various environments, making transfer and dispensing tasks easier.
The PICO unit has been designed by PIUSI engineers to offer users maximum practicality, simple operation, and long-term reliability.
Ready to Use: The kit includes the necessary basic accessories for quick commissioning.
Versatile Application: Ideally suited for transferring diesel, HVO/XTL fuels, and other fluids such as antifreeze and windscreen washer fluid.
Robust Construction: The PICO pump features a universal motor and a double-insulated casing, guaranteeing solid and durable operation.
Weather-Resistant Materials: The materials used are resistant to external influences, ensuring a long service life.
Compact and Lightweight: Its small size and weight (approx. 6 kg) facilitate portability and placement.
Integrated Switch: The built-in switch on the device makes turning it on and off simple.
All PICO units include the essential elements required for fluid transfer as standard:
Suction and Discharge Hose: For fluid intake and outlet.
Filter: A bottom-mounted suction filter ensures that only fluid free of contaminants enters the pump.
Manual Dispensing Nozzle: Standard configurations include a manual dispensing nozzle.
Power Cables:
2-meter power cable with Shuko plug (for 230 V AC mains power supply).
3-meter power cable with clips (for 12 V and 24 V DC battery operation).
The PICO unit can be optionally equipped With K24 type electronic turbine flow meter. This accessory significantly increases dosing accuracy and verifiability:
Accuracy: +/- 1% measuring accuracy.
Dispensing Gun: Can be paired with an automatic dispensing gun.
The PICO fluid transfer unit is available in different voltage and dosing options. The table below shows the main configurations available:
| Product code | Description | Dispensing Gun Type | Tápellátás |
|---|---|---|---|
| F00202000 | PICO 230V | Manual (Manual) | 230V AC |
| F00202010 | PICO 230V | Automatic (Automatic) | 230V AC |
| F00202040 | PICO 12V | Manual (Manual) | 12V DC |
| F00202050 | PICO 12V | Automatic (Automatic) | 12V DC |
Note: 24V DC versions are also available, which are supplied with 12V cabling (clips).
| Parameter | Details |
|---|---|
| Product Category | Fuel, Lubricant Fluid |
| Application Area | Agriculture, Industry |
| Pump Type | Centrifugal |
| Motor | Universal, double insulated housing |
| Power Supply Options | Battery (12V/24V DC) or Mains (230V AC) |
| Hose Length (Hose) | 4 méter |
| Connection to the Drum | 2” BSP and M 64×4 |
| Optional Metering Unit | K24 Turbine Flow Meter (+/- 1% accuracy) |
PICO can be ideally integrated into the following sectors:
Agriculture: On-site refueling of vehicles, tractors, and agricultural machinery.
Construction Industry: Refueling of high-power construction machinery and equipment.
Industrial Sites: Internal logistics systems where mobile or temporary transfer stations are needed.
Service and Maintenance: Quick and clean dispensing of antifreeze or windscreen washer fluids.
Thanks to the compact design of the PICO and the availability of different voltage options (12V/24V DC and 230V AC), the PIUSI PICO is one of the most flexible portable fluid transfer solutions on the market.
