This detailed description presents the platform offered by Consul GmbH, specifically designed for headlight adjustment systems (LEG), which is an ideal accessory for Consul 4-post lifts. The product aims to ensure precise and safe operation during the calibration of vehicle headlights.
The headlight adjustment platform (LEG) can be mounted on the original guide rails provided by the manufacturer. The structure is protected by an additional channel profile, which prevents the accidental falling of the headlight adjustment system during the workflow. This platform is compatible with all Consul 4-post lifts, ensuring flexible usability in workshops.
The design of the platform guarantees maximum stability and easy access. The structural components are designed to provide optimal performance during both installation and use.
Highlighted Design Features:
Galvanized Grating Beam: The main supporting structure has a galvanized grating design, which provides excellent durability and a slip-free surface for driving the vehicle onto it.
Railing Made of Galvanized Channel Profile: The anti-fall railing is made of a galvanized channel profile, which provides extra protection and increases safety.
Drive-on Ramps: Drive-on ramps can be fitted on both ends, facilitating the driving on and off of vehicles onto the platform.
The platform must be ordered depending on the type of lift and the existing headlight adjustment system. For exact fitment, the precise type of lift and the details of the adjustment system must be provided when ordering.
Series-Specific Part Numbers:
| Lift Series | Part No. | Note |
|---|---|---|
| 4.45 Series | 593400 | Required for the basic LEG equipment. |
| 4.55 Series | 577650 | Required for the basic LEG equipment. |
| Third-Party Product (590067) | 593400 | For adaptation to a third-party product, it must be ordered together with part number 593400. |
Optional Spare Parts:
The product is part of the wide portfolio of Consul workshop equipment, categorized under Special Solutions – ATLAN.
| Property | Value |
|---|---|
| Product Name | Platform for light adjustment (Headlight Adjustment Platform) |
| SKU (Item Number) | 600148-4 |
| Category | Special Solutions – ATLAN |
| Compatibility | With all Consul 4-post lifts |
| Main Material (Beam) | Galvanized grating |
| Railing Material | Galvanized channel section |
| Accessories | Drive-on ramps (mountable on both ends) |
The platform must be attached to the existing guide rails supplied by the original manufacturer. The beam is equipped with special fastening elements that allow for precise adjustment to the crossbeam and the floor. This flexibility ensures that the platform perfectly integrates with the workshop's existing infrastructure and the specific headlight adjustment system.
Knowledge of the exact lift type and the specifications of the headlight adjustment system may be required for installation at the time of order, especially for retrofitting existing lifts.
By using the Consul headlight adjustment platform, workshops can significantly improve the efficiency and safety of the headlight adjustment process:
Increased Safety: The stable, galvanized grating surface and the robust railing minimize the risk of accidents during work at height.
Precise Positioning: The platform allows vehicles to be positioned at the ideal height and position for headlight calibration, which is essential for modern vehicles.
Flexible Integration: Compatibility with the entire Consul 4-post lift range and adaptability to third-party systems ensure that the platform will work with almost any existing equipment.
Durability: The galvanized and electro-galvanized elements provide excellent resistance to corrosion and the physical stress typical of the workshop environment.
This accessory reflects the commitment of Consul Werkstattausrüstung GmbH to professional, safe, and efficient vehicle service solutions.
