Part number: 700823
This detailed product description presents the Wieländer+Schill S8 type closing tool, specifically designed for the professional and reliable fastening of Self Piercing Rivets (SPR) in automotive body repair and semi-industrial applications. The tool is part of the XSeries product line, representing professional riveting technology, guaranteeing high quality and durable performance.
The S8 closing tool is a precision component essential for applying the correct closing force and achieving optimal rivet head formation when using SPR technology. The use of self-piercing rivets is becoming increasingly common in modern vehicle body structures as they allow for joining two or more metal sheets without the need for pre-drilling, thereby increasing structural integrity and reducing working time.
This specific closing tool fits ideally for 5.3 mm diameter and 6.5 mm long self-piercing rivets. The design of the tool ensures that the rivet deforms in the desired manner during pressing, creating a solid, durable connection between the joined elements. Precise fit is crucial during body repairs where structural strength and corrosion protection are of paramount importance.
Wieländer+Schill tools are made from high-quality materials that resist high mechanical stress and wear resulting from frequent use. This durability ensures a long service life for the tool and continuously reliable operation in the workshop environment.
The specifications of the S8 closing tool ensure compatibility and precise operation with the appropriate riveting machines (most likely XSeries systems).
| Characteristic | Value | Note |
|---|---|---|
| Product Type | Closing Die (Closing Die) | For SPR rivets |
| Part number | 700823 | Unique Identifier |
| Compatible SPR Diameter | 5.3 mm | Rivet Diameter |
| Compatible SPR Length | 6.5 mm | Rivet Length |
| Total Length | 18 mm | The outer dimension of the tool |
| Total Width | 17.5 mm | The outer dimension of the tool |
| Total Height | 28.2 mm | The outer dimension of the tool |
| Product Family | XSeries – Professional Riveting Technology | Wieländer+Schill premium category |
Precise Design: The geometry of the tool is specifically calibrated for the optimal forming of the closing head of 5.3 mm diameter SPR rivets.
Robust Construction: Made from high-quality steel alloy, which guarantees the tool's resistance to high pressing forces.
Moduláris Kompatibilitás: Can be integrated into the XSeries system, ensuring quick changeover and efficient work execution.
Long Lifespan: The tool's wear-resistant surfaces minimize the need for replacement, reducing operating costs.
Using the S8 closing tool, professionals benefit from the following advantages:
Structural Integrity: A properly seated rivet guarantees the firm and durable connection of body panels, which is critical for safety-relevant repairs.
Efficiency: The fast and precise fit reduces repair time, increasing workshop productivity.
OEM Compliance: Wieländer+Schill products often comply with the strict requirements of vehicle manufacturers (OEM), ensuring that repairs meet factory quality standards.
Easy Maintenance: The dimensions and design of the tool facilitate cleaning and installation into the riveting machine.
This closing tool is an essential accessory for any professional workshop performing high-quality, rivet-based body repairs on modern vehicles. Precise sizing and reliable material use guarantee that every single rivet joint meets the highest quality requirements.
