The SSC 35/25 short stroke cylinder is a key element of Wieländer+Schill's XSeries professional riveting technology. This robust, steel hydraulic cylinder is ideally suited for high-precision, repetitive pressing and setting tasks, especially in vehicle repair and metalworking environments.
The cylinder achieves optimal performance when PowerPack 1000 SC used in conjunction with a hydraulic power unit, which enables the achievement of maximum setting force. This combination ensures reliable and controlled operation even in the most demanding applications.
The compact dimensions and high force of the SSC 35/25 cylinder make it ideal for situations where space is limited but high power transmission is required.
High Force Transmission: When operated with the appropriate power unit (PowerPack 1000 SC), it can achieve up to 69 kN maximum setting force, guaranteeing efficient work performance.
Precision Stroke: The precisely defined a 25 mm stroke length ensures the reproducibility of settings and the precise positioning of workpieces.
Robust Construction: Made entirely of steel, manufactured, which ensures a long service life and excellent resistance to mechanical stress.
Long-Life Coating: The cylinder surface has a burnished features a coating that increases wear resistance and improves surface quality.
Wide Temperature Range: Designed to operate reliably between 5 °C and 55 °C operating temperature range.
The table below details the critical technical parameters of the SSC 35/25 short stroke cylinder:
| Parameter | Value | Unit of Measure | Note |
|---|---|---|---|
| Part number | 700060 | – | Unique Identifier |
| Stroke | 25 | mm | Specified Stroke Length |
| Force (Maximum) | 77 | kN | The cylinder's own maximum force (without load) |
| Force (Setting, with PowerPack 1000 SC) | 69 | kN | Maximum setting force with the power unit |
| Diameter (Ø) | 56 | mm | Outer diameter of the cylinder |
| Length | 144 | mm | Total length of the cylinder |
| Overall Dimensions (L x W x H) | 60 x 56 x 147 | mm | The spatial extension of the cylinder |
| Material | Steel | – | Robust structural material |
| Operating Temperature | 5 – 55 | °C | Operating range |
| Weight | 1,470 | kg | Net weight of the tool |
| Coating | Burnished | – | Wear-resistant surface treatment |
The SSC 35/25 cylinder is an ideal choice for the following areas:
Body Repair: For the on-site setting and pressing of elements requiring precise fit and fastening (e.g., reinforcements, plates).
Riveting Operations: When installing high-strength rivets as part of XSeries systems, where precise force application is essential.
Semi-industrial Assembly: Any manufacturing process requiring short-stroke, high-precision hydraulic force.
This short-stroke cylinder reflects Wieländer+Schill's commitment to quality, durability, and professional performance in the automotive repair industry. The product is manufactured in an environment with the highest quality standards, holding an ISO 9001 certificate.
