The Gartec RA2055 part number, enclosed hose reel, has been designed for the most demanding industrial environments, specifically for high-pressure greasing. This robust construction guarantees reliable and safe fluid handling where durability and high performance are essential.
This model is part of the Gartec Standard series, which is an outstanding element of systems specialized for the efficient and safe conveyance of fluids. The enclosed design offers maximum protection for the hose and internal mechanism against external contamination and harsh industrial conditions.
The RA2055 hose reel is designed to withstand the toughest operating conditions while providing optimal performance in handling high-viscosity materials such as grease.
Extreme Pressure Rating: Capable of safely operating up to 600 bar (8700 PSI) working pressure, making it ideal for high-pressure greasing systems.
Robust Construction: The main structure is made of painted steel, providing excellent resistance against corrosion and mechanical damage.
Reinforced Roller: The hose guide roller is made of reinforced, glass-fiber-reinforced polypropylene (PP), which increases durability and ensures the hose retracts evenly.
Enclosed Design: The fully enclosed housing protects the hose from physical damage, dust, moisture, and chemicals, extending the hose's lifespan.
High Capacity: Capable of accommodating hoses up to 15 meters long, providing flexibility over large work areas.
Simple Integration: Features standard connections for easy installation into existing systems.
This high-performance hose reel is primarily applicable in industrial sectors where regular and reliable high-pressure lubrication is required:
Heavy machinery manufacturing and maintenance
Steel industry and metallurgy
Maintenance of mining and construction machinery
Servicing of heavy-duty vehicles
General heavy industry lubrication points
The table below details the critical technical parameters of the Gartec RA2055 model:
| Parameter | Value | Note |
|---|---|---|
| Part number | RA2055 | |
| Típus | Enclosed hose reel | For high-pressure greasing |
| Operating Pressure (Max.) | 600 bar / 8700 PSI | |
| Hose Capacity (Max.) | 15 meters | |
| Transport Medium | Grease (Grease) | |
| Structural Material | Painted steel | |
| Wheel Material | Glass-fiber-reinforced polypropylene | Reinforced design |
| Inlet Connection | 1/4″ F (Female) | |
| Outlet Connection | 1/4″ M (Male) | |
| Weight (Kg) | 17 kg | Net Weight |
| Packaging Dimensions (mm) | 570 x 275 x 595 |
Physical dimensions of the product (main extents of the hose reel housing):
| Size Designation | Dimension (mm) |
|---|---|
| A | 590 mm |
| B | 543 mm |
| C | 205 mm |
Note: The dimensions should be understood based on the drawn diagrams, where A, B, and C indicate the main extents.
This specific model is grease optimized for delivery, ensuring the efficient and pressure-loss-free transport of high-viscosity materials to the point of operation. Although Gartec offers a wide range of options for other fluids (e.g., waste oil, new oil, AdBlue, water, antifreeze), the RA2055 is the specialist for high-pressure greasing tasks.
Gartec is committed to long-lasting solutions. The closed housing of the RA2055 not only provides protection but also contributes to the overall aesthetics of the system by maintaining clean, tidy workspaces. The painted steel surface resists frequent cleaning and corrosive environmental effects, which is crucial in continuously operating industrial facilities. The reinforced roller ensures the hose is not damaged during retraction, even when the hose is under high pressure.
This product is an ideal choice for professionals seeking a reliable, heavy-duty, maintenance-free solution for supplying critical lubrication points.
