Part Number: 700239
This professional tool set, offered by Wieländer+Schill, is specifically designed for the professional and efficient removal of self-piercing rivets (SPR – Self Piercing Rivets) removal. The set belongs to the Wieländer+Schill XSeries – Professional Riveting Technology product line, ensuring the precision and reliability required during body repair work.
This tool set is the ideal choice for any technician who wants to remove 3.2 mm diameter self-piercing rivets seamlessly, quickly, and reliably, thereby minimizing the risk of damage to the surrounding material.
A D3 + D19 Tool Set contains two essential components that work together to ensure the optimal rivet removal process: a special extraction mandrel and a corresponding extraction die.
The set with part number 700239 includes the following components:
| Component | Part number | Description | Field of application |
|---|---|---|---|
| D3 Extraction Mandrel | 700800 | Extraction mandrel designed for self-piercing rivets (SPR). | For rivets with a diameter between 3.2 mm and 5.0 mm. |
| D19 Extraction Die | 700806 | Special extraction die. | Self-piercing rivets with a 3.2 mm diameter. |
This mandrel is the active element for rivet removal. Its design guarantees that it precisely grips the rivet head and pulls the rivet body out of the hole in the appropriate manner.
Compatibility: Optimized specifically for self-piercing rivets.
Diameter Range: Flexibly usable for SPR rivets ranging from 3.2 mm up to 5.0 mm in diameter, which increases the versatility of the tool set.
Extraction Mechanism: Designed in such a way that it does not excessively damage the rivet material during extraction, thus facilitating subsequent repair or fitting work.
The D19 die forms the counter-side to the mandrel, ensuring stable support and correct positioning of the rivet head during the extraction process.
Precise Fit: Calibrated specifically for 3.2 mm diameter self-piercing rivets.
Stability: Prevents the rivet from rotating or damaging the surrounding panel under high force.
Durability: The tools are made from high-quality materials that withstand high mechanical stress and frequent use.
The product is manufactured in accordance with the strict quality standards of Wieländer+Schill, ensuring long service life and reliable performance in the body repair sector.
| Parameter | Value | Note |
|---|---|---|
| Product Family | XSeries – Professional Riveting Technology | Tools designed for heavy-duty use. |
| Main Function | Rivet Extraction | For removing self-piercing rivets (SPR). |
| Set Part Number | 700239 | Identifier for the complete D3 + D19 set. |
| D3 Mandrel Part Number | 700800 | Puller mandrel. |
| D19 Die Part Number | 700806 | Puller die. |
| Target SPR Diameter (D19) | 3.2 mm | The specific dimension of the die. |
| D3 Mandrel Diameter Compatibility | 3.2 mm – 5.0 mm | The mandrel can be used across a wider range. |
| Application Environment | Body repair, metalworking | For professional workshop use. |
By using the D3 + D19 tool set, professionals gain significant advantages during the repair process:
Precise Removal: The symmetrical design of the tools minimizes the deformation of the material surrounding the rivet (e.g., body panel), which is critical for high-quality repairs.
Time Saving: The efficient extraction mechanism speeds up the replacement of damaged fasteners, thereby increasing workshop productivity.
System Compatibility: The wider diameter range of the D3 mandrel (3.2-5.0 mm) means that a single set can handle several different sizes of SPR rivets, reducing the number of tools required.
WS Quality: Wieländer+Schill products guarantee a long tool life, even under the toughest industrial conditions, thanks to the use of high-quality steels and precision manufacturing processes.
This tool set is an essential part of equipping modern body repair shops, especially in cases where vehicle manufacturers increasingly use self-piercing riveting technology for fastening components. The set ensures that the repair process meets the highest professional requirements.
