This detailed product description presents the Wieländer+Schill Tool Box RS-14 | SPR retrofit kit, specifically designed for the PushPull PP 90 riveting machine for processing self-piercing rivets (SPR). This kit is an essential tool for professionally performing automotive repair and metalworking tasks, ensuring precise and reliable connections.
The Tool Box RS-14 | SPR is a comprehensive package that enables the extension of the functions of the existing PushPull PP 90 hydraulic riveting machine to handle the specific dimensions of self-piercing rivets (SPR). SPR technology is a modern, heat-treatment-free alternative for riveting body parts, providing excellent joint strength.
The kit includes the necessary tools for processing SPR rivets in two different sizes, as well as a practical plastic/steel toolbox for secure storage and transport of the components.
Special Application: Optimized exclusively for setting self-piercing rivets (SPR).
Compatibility: Directly to the PushPull PP 90 retrofit kit designed for the riveting machine.
Handling Two Sizes: Includes a tool set for two different sizes (Ø 5 mm and Ø 3 mm), maximizing flexibility across various applications.
Durability: The tools are made of high-quality steel, while the storage box is made of durable plastic.
Organized Storage: The included Tool Box ensures that every component is clearly visible and protected in the workshop environment.
The kit features precise technical parameters that guarantee professional performance.
| Property | Value | Note |
|---|---|---|
| Part number | 700212 | Identifier of the complete kit |
| Length × Width × Height | 270 x 84 x 56 mm | Dimensions of the storage box |
| Material composition | Plastic, Steel (kunststoff) | Material of the box and tools |
| Weight | 0.350 kg | Net weight of the complete kit |
| Content | 1 set | Total unit of the package |
The Tool Box RS-14 | SPR includes the following key components:
Application: Setting of SPR rivets.
Size: Ø 5 mm.
Components:
700260 E1: Setting die for SPR rivets.
700261 E2: Closing die for SPR rivets.
Application: Setting of SPR rivets.
Size: Ø 3 mm (The accessory information also mentions Ø 3.5 mm, but the main description refers to Ø 3 mm, which, according to the set's specification, is the D die set).
Components:
700332 D1: Setting die for SPR rivets.
700262 D2: Closing die for SPR rivets.
Type: Extension.
Hossz: 28 mm. This element ensures the correct distance and force application during the riveting process.
For professional execution, further accessories available for separate purchase are compatible with this system:
This set is a detailed description of die set part no. 700226, which is required for 5 mm diameter SPR rivets.
Contents:
1 pc 700260 E1 (Setting die for SPR)
1 pc 700261 E2 (Closing die for SPR)
Function: Setting of self-piercing rivets with a diameter of 5 mm.
This set is a detailed description of die set part no. 700227, which is used for smaller diameter SPR rivets.
Contents:
1 pc 700332 D1 (Setting die for SPR)
1 pc 700262 D2 (Closing die for SPR)
Function: Setting of self-piercing rivets with a diameter of 3.5 mm.
This tool does not provide assistance for riveting, but for the maintenance and replacement of tools.
Important Warning: FORBIDDEN to use for tightening!
Application: Exclusively used for loosening and removing dies, punches, ejector pins, and extensions.
The Tool Box RS-14 | SPR set is the ideal choice for any professional who:
In Vehicle Repair Shops works, especially during body repair work.
Self-piercing riveting technology is applied where traditional welding cannot be used (e.g., in the case of dissimilar metals or sensitive materials).
Requires professional, OEM-compatible joining quality.
This set is an integral part of the Wieländer+Schill XSeries professional riveting technology, which prioritizes reliability and efficiency. The precision-machined steel components guarantee long service life and consistent performance in every riveting cycle.
