The Leitenberger RTS 01 room thermostat is a reliable and robust solution for precise temperature control, especially for applications requiring measurement with a side sensor. „Made in Germany” quality guarantees long service life and reliable operation in both industrial and commercial environments.
This thermostat is the ideal choice for controlling heating and cooling systems, as well as other temperature-sensitive processes where maintaining a precise and stable temperature range is essential.
The RTS 01 thermostat is designed to meet strict industrial requirements while providing simple and intuitive operation.
Robust Design: The housing made of ABS plastic, light grey (RAL 7035), guarantees durability.
Appropriate Protection: Thanks to its IP44 protection rating, it is resistant to splashing water and the ingress of solid particles, making it suitable for installation in workshops and technical rooms.
Two Selectable Measuring Ranges: Flexibly adapts to different temperature requirements thanks to the two available scales.
High-Capacity Relay: The built-in 1 SPDT relay has a load capacity of 16 A / 250 V, ensuring wide compatibility with various control circuits.
Side Sensor: Measurement via the side-mounted probe allows for precise detection of the temperature at the desired point.
The table below details the critical technical parameters of the RTS 01 room thermostat:
| Parameter | Value | Note |
|---|---|---|
| Part number | RTS 01 | Basic model identifier |
| Housing Material | ABS Plastic | RAL 7035, light grey |
| Protection Rating | IP 44 | Dust and splash-proof |
| Measuring Range 1 | Between -35 °C and +35 °C | Order code: RTS01_35035 |
| Measuring Range 2 | Between 0 °C and +40 °C | Order code: RTS01_00040 |
| Differential (Hysteresis) | $Delta T = 3 pm 1 text{ K}$ | The degree of oscillation around the set value |
| Maximum Probe Temperature | $+60 text{ °C}$ | Maximum allowable temperature of the probe |
| Switch Type | 1 pc SPDT relay | Single-pole, two-position changeover contact |
| Maximum Load | $16 text{ A} / 250 text{ V}$ | Electrical switching capacity |
| Sensor Placement | With side probe | Location of measurement |
Due to the versatility of the RTS 01 thermostat, it can be used in numerous industrial and commercial segments:
Refrigeration technology: Maintaining stable temperature in cold rooms, cold stores or industrial refrigeration equipment where operation within the set range is critical.
Building services engineering: Control of central heating and air conditioning systems, ensuring energy-efficient operation.
Industrial Measurement and Control Technology: Monitoring and controlling processes where maintaining the ambient temperature within strict limits is necessary.
Automotive Applications: Although primarily a room thermostat, it can also be used in special automotive test environments due to its robust design (for auxiliary measurements).
The installation of the RTS 01 room thermostat is simple, thanks to its standard design and easily accessible connections. The placement of the side probe allows for optimal temperature measurement in the desired zone.
The set temperature can be easily adjusted on the scale found on the front of the device. The $Delta T = 3 pm 1 text{ K}$ hysteresis ensures that the system does not switch too frequently, thus increasing service life and reducing energy consumption.
Manufactured according to Leitenberger's quality assurance principles, the RTS 01 guarantees that the set temperature values are maintained reliably over the long term. Detailed technical documentation (in PDF format) is also available on the manufacturer's website.
