This detailed product description presents the premium category, Z3 marked, solid carbide end mill bit from Wieländer+Schill, developed specifically for the VarioDrill WS 90 system. This tool belongs to the category of separating tools and is excellently suited for precise drilling and milling tasks, especially during automotive body repairs.
The end mill bit with item number 627010 is optimized for the effective machining of high-strength steels, ensuring long service life and excellent surface quality.
This Z3 end mill bit is a member of the Wieländer+Schill separating tool family, which caters to the highest level of professional demands.
Excellent Material Quality: The tool is made from a combination of HSS (High-Speed Steel) and Carbide (Solid Carbide), which guarantees exceptional wear resistance and tool longevity, even under extreme loads.
Optimized Geometry: The Z3 marking refers to a design with three cutting edges (3 flutes), which is ideal for fast and clean material removal while minimizing vibration and heat generation.
Precise Sizing: The nominal diameter of 6.7 mm and the total length of 49.0 mm ensure precise fit and reliable performance in compatible tool systems.
Broad Compatibility: Specifically recommended for the VarioDrill WS 90 series, which is a cornerstone of body repair technologies.
The table below summarizes the product's critical technical parameters, which are essential for selecting the correct application:
| Property | Value | Note |
|---|---|---|
| Part number | 627010 | The unique identifier of the product |
| Package contents | 1 darab | Contents of the package |
| Diameter (Ø) | 6.7 mm | Nominal diameter of the cutting edge |
| Number of flutes (Z) | 3 | End Mill Geometry |
| Total Length | 49.0 mm | Total length of the tool |
| Material | HSS, VHM | High-Speed Steel and Solid Carbide |
| Shank diameter | 8.0 mm | The diameter of the gripping part |
| Weight | 0.020 kg | Product weight |
| Outer Dimensions (L x W x H) | 8 x 8 x 48.8 mm | Physical dimensions of the tool |
This solid carbide end mill is primarily designed for use in the automotive body repair sector, where the precise machining of high-strength steels (e.g., UHSS, AHSS) is crucial.
Ideal Usage:
Removal of Spot Welds: The end mill is excellently suited for the fast and clean removal of the head section of a spot-welded joint, preparing the surface for panel replacement.
Drilling Preparation: Used for creating precise holes where tool stability and cutting edge sharpness are critical.
Materials: Specifically recommended for high-strength automotive body steels.
Maximizing Performance:
To increase tool life and cutting efficiency, the use of a suitable cutting fluid is strongly recommended. Among the accessories related to the product, you can find the BTR/BOR Fluid (Item number 628000 or 648007), which is a silicone-free cutting oil. This oil significantly increases the lifespan of cutters, drills, and saws, especially when machining high-strength body steels, ensuring optimal cutting performance.
The use of the appropriate lubricant is essential for professional work.
| Product | Part number | Description |
|---|---|---|
| BTR/BOR Fluid | 628000 | 125 ml packaging. Silicone-free cutting oil, increases the service life of tools on high-strength steels. |
| BTR/BOR Fluid | 648007 | 50 ml packaging. The same silicone-free formulation, ideal for smaller workshops or testing purposes. |
This solid carbide milling insert represents the quality of Wieländer+Schill, guaranteeing reliability and precision during all body repair tasks.
