This product is For VAS 6545B Resistance Spot Welding Machine A developed, special electrode set, specifically designed in accordance with the standards for Volkswagen AG workshop equipment. The set is ideal for precise and efficient spot welding tasks, especially on hard-to-reach surfaces.
A VAS 6545B/9 Electrode Set No. 11 An assembly configured at a 90° angle, featuring 16 mm diameter electrode caps, and optimized for use with C-arm No. 1. This configuration ensures optimal access to the welding spot, even in tight spaces.
This electrode set is essential for professional body repair work, as the 90° design allows access to welding points in areas where straight electrodes cannot be used. The set includes the necessary components for quick and reliable operation.
Area of application:
Spot welding with the VAS 6545B welding machine.
As part of the workshop equipment specified by Volkswagen AG.
Ideal for tight corners and restricted access areas thanks to the 90° angle.
High-Quality Material Usage:
The electrodes CuCrZr (Copper-Chromium-Zirconium) made of an alloy that provides excellent electrical conductivity and high wear resistance, guaranteeing long service life and stable welding quality.
The VAS 6545B/9 set forms a complete unit consisting of the following elements:
| Part number | Description | Quantity |
|---|---|---|
| 495623 | Electrode | 1 stück |
| 495622 | Electrode | 1 stück |
Detailed Contents:
1 pc 495623 Electrode: 28 mm long, part of Electrode Set No. 11.
1 pc 495622 Electrode: 121 mm long, part of Electrode Set No. 11.
Contents: 1 set
Precise dimensions and material characteristics are essential for achieving precise welding parameters.
| Property | Value | Note |
|---|---|---|
| Part number | 932018NG | Factory Identifier |
| Compatibility | VAS 6545B | Resistance Spot Welding Machine |
| C-Arm Compatibility | C-Arm No. 1 | |
| Angle | 90° | Angled design |
| Electrode Cap Diameter (Ø) | 16 mm | |
| Length (Longer electrode) | 121 mm | Part number: 495622 |
| Length (Shorter electrode) | 28 mm | Part number: 495623 |
| Total Dimensions (Length x Width x Height) | 81 x 48 x Ø 28 mm | External dimensions for the set (approximate) |
| Material | CuCrZr (Copper-Chromium-Zirconium) | Excellent thermal and electrical conductivity |
| Thread | Not specified (In place of weight data) | The weight data is available at the source location |
| Weight | 0.590 kg | Total weight of the package |
| Work window (Work window) | 70 x 150 mm | Specification for the welding area |
This electrode set provides optimal performance when used with accessories suitable for the VAS 6545B welding machine.
The components of the set are also available separately, as well as other accessories that support the welding process:
Electrode | 121 mm | Electrode Set No. 11 (Part No.: 495622): This is the longer electrode, equipped with a cooling tube and a copper sealing washer. It can only be used together with the 28 mm electrode as part of Set No. 11.
Electrode | 28 mm | Electrode Set No. 11 (Part No.: 495623): This is the shorter electrode, which includes an electrode cap. It can only be used together with the 121 mm electrode as part of Set No. 11.
Electrode Holder C-arm No. 4 / No. 6 / No. 7 (Part No.: 495692): Holder element that is also compatible with other C-arm types.
Electrode Caps | Ø 16 mm | Type A-32 (Part No.: 497096): Available in a pack of 6, with a length of 20 mm. Recommended exclusively for automatic programmed welding with the C-Trafogun GT-V6 device.
If you need an electrode with a different angle or configuration, the following sets are also available:
VAS 6545B/6 Electrode mounting C-arm with tilting device: Ideal for welding very narrow metal strips. Thanks to the concentric electrodes, the welding point is shifted outward from the center, allowing penetration into every corner. (Part Number: 932015NG)
VAS 6545B/7 Electrode Set No. 7 | 90° Angle: Another set with a 90° angle, containing different types of electrodes and holders (e.g., curved, short curved electrodes). (Part Number: 932016NG)
VAS 6545B/8 Electrode Set No. 9 | 38° Angle: This set is adjustable to a 38° angle, also with 16 mm caps for the C-arm No. 1. (Part Number: 932017NG)
Wieländer+Schill products comply with the highest industrial standards. The product belongs to the Volkswagen AG Workshop Equipment category, which guarantees a perfect fit with original parts and adherence to factory specifications. The company holds ISO 9001 and ISO 14001 certifications, confirming its commitment to quality management and environmental protection.
This set is an essential tool for any professional performing top-level body repair work, ensuring fast, precise, and durable spot welds.
