This detailed product description is for the VAS 6957 Countersink Tool presents, which is specifically designed for precision hole machining, especially when installing screws and rivets. This tool is part of the official range of workshop equipment from Volkswagen AG and belongs to the Wieländer+Schill professional bodywork special tools category.
The VAS 6957 is an excellent quality 100° countersink, featuring an integrated depth stop and pilot, ensuring perfect and repeatable results in every application.
This 3-piece set is the ideal choice for precision work where achieving the exact countersink depth and angle is essential.
Precision Countersinking: The 100° angle is ideal for standard countersunk screw heads and rivets, ensuring a perfect fit flush with the surface.
Integrated Depth Stop: The built-in depth stop guarantees that the countersinking is always done to the predefined depth, preventing excessive material removal or incorrect surface finish.
Pilot Function: The 6.6 mm diameter pilot ensures centering of the tool in the existing hole, thereby increasing the accuracy of the workpiece and minimizing the risk of tool displacement.
Excellent Material Quality: Made from a combination of HSS (High-Speed Steel) and steel, ensuring long service life and excellent wear resistance even under heavy use.
High-Speed Operation: The tool can be safely used at a maximum speed of up to 3000 revolutions/minute, enabling efficient work performance.
The VAS 6957 countersink tool has been developed to meet the highest quality requirements. The table below summarizes the key technical parameters:
| Property | Spezification |
|---|---|
| Product Identifier | VAS 6957 |
| Part number | 932158 |
| Design | Countersink 100° with depth stop and pilot |
| Content | 3-piece set (1 set) |
| Angle | 100° |
| Pilot Diameter (Pilot Ø) | 6.6 mm |
| Total Length | 83.0 mm |
| Shank Diameter | 8.0 mm |
| Maximum Rotational Speed (Speed) | 3000 RPM (revolutions per minute) |
| Material | HSS (High-Speed Steel), Steel |
| Weight | 0.141 kg |
This special tool is essential in modern vehicle repair, especially in the following areas:
Body Repair: Creating precise countersinks for fastening body parts, where the screw or rivet head must be flush with the surface.
OEM Specification Compliance: As it is categorized as official workshop equipment for Volkswagen AG, it is guaranteed to meet the tolerances and procedures prescribed by the manufacturer.
Rivet Jobs: Ideal preparation for high-strength structural rivets, ensuring the correct seating surface.
Wieländer+Schill is committed to the highest quality, which is also proven by the following certifications:
ISO 9001: Quality Management System Certificate.
ISO 14001: Environmental Management System Certificate.
These standards ensure that strict quality control processes were applied during the manufacture of the VAS 6957 tool, guaranteeing reliability and durability.
The VAS 6957 tool is available through authorized distributors or the local Volkswagen importer. The tools are designed for professional use and are the foundation of precision work.
