The Wieländer+Schill VAS 892 011 type wet dust extractor is a professional device specifically designed for the effective and safe separation of various types of dust and particulates. This system offers an ideal solution for workshop environments where maintaining air quality and handling hazardous materials are critical.
The operating principle of the device is based on introducing dust particles into a liquid medium, thereby rendering them harmless and non-combustible. It is particularly suitable for handling aluminum and magnesium dusts, and thanks to the additionally built-in, Class H residual dust filter, it also effectively vacuums CFRP (carbon fiber reinforced plastic) dust.
This model is part of the Volkswagen AG workshop equipment recommendations, ensuring compliance with strict quality and safety regulations.
The VAS 892 011 wet dust extractor features several functions that facilitate maintenance and increase safety during daily use:
Accurate Pressure Indication: The device provides precise feedback on the differential and negative pressure, helping the user continuously monitor the suction performance.
Easy Maintenance: Tank emptying and cleaning can be performed extremely easily, minimizing downtime.
Convenient Filter Change: The design of the filtration system allows for quick and trouble-free replacement of filter inserts.
High Performance in a Compact Size: The device provides high suction power while maintaining its compact physical dimensions, making it easy to maneuver and store.
Efficient Unit Cooling: The built-in cooling system ensures optimal motor temperature, increasing the lifespan of the device even under intensive use.
Optical Level Monitoring with Auxiliary Sensor: In addition to optical monitoring of the liquid level, an auxiliary level sensor has been integrated for even more reliable level monitoring.
The detailed technical parameters of the VAS 892 011 wet dust extractor are as follows:
| Parameter | Value | Note |
|---|---|---|
| Part number | 932217 | |
| Típus | Wet Dust Extractor NA7-26 | |
| Dust class | H, M | Class H filtration, suitable for hazardous dusts. |
| Content (Capacity) | 7 l | |
| Mains Voltage | 110 V | UL (American standard) compatible design. |
| Power Consumption | 2.6 – 2.89 kW | |
| Rated Air Flow (Fuse) | 32 A | |
| Max. Negative Pressure | -160 mbar | |
| Max. Volume Flow Rate | 220 m³/h | |
| Protection Class | IP 54 | Dust and splash protection. |
| Noise Level (Sound Pressure Level) | 68 dB(A) | Favorable noise level for the working environment. |
| Weight | 98 kg | |
| Dimensions (Length x Width x Height) | 802 x 595 x 755 mm | Compact design. |
| Marking | Zone 22, according to ATEX II3D | Certified for use in explosive atmospheres (in case of non-combustible dusts). |
| Conformity Declaration | According to 2006/42/EC | Machinery Directive conformity. |
The VAS 892 011 wet dust extractor is supplied fully equipped, ready for immediate operation:
1 pc Wet dust extractor NA7-26 unit
1 pc Accessory box
1 pc Hose support (stainless steel, pre-installed)
1 pc Cable support (stainless steel, pre-installed)
1 pc Push bar (350 mm length, Ø 20 mm diameter)
1 pc Plastic suction hose (5 m length, Ø 50 mm diameter)
1 pc Bent hose (with connector on both ends, Ø 50 mm diameter)
1 pc Hose (1000 mm length, Ø 50 mm diameter)
1 pc Industrial floor suction nozzle (500 mm width)
1 pc Transition coupling:
Connector A: With 50 mm outer diameter spigot
Connector B: Storz C 50 mm coupling
1 pc Suction head (60 x 12 mm, cupped design)
1 pc Power supply cable (10 m long)
For maximum efficiency and long service life, the use of the following accessories is recommended:
Part number: 881759
This accessory further enhances the moisture-trapping capacity of the equipment, protecting internal components from excessive vapor or liquid ingress.
Part number: 881758
This filter cartridge meets the requirements of the H dust class and ensures the highest filtration efficiency. Its maximum penetration rate is less than 0.005%. It is specifically recommended for applications where the OEL (Occupational Exposure Limit) is less than 0.1 mg/m³, including the handling of carcinogenic substances.
The VAS 892 011 wet dust separator represents the quality and reliability of Wieländer+Schill, ensuring a clean and safe working environment for the most demanding automotive and industrial users.
